SKU: DellR630 Category: Brand: ,
Request a quote Email SKU

Enterprise stock · tested · export documentation available

Dell EMC PowerEdge R630 Server — Product Resource List

Documentation and Resource List

  • Dell PowerEdge R630 Spec Sheet (English)

  • Dell PowerEdge R630 Owner’s Manual — System Overview

  • Dell PowerEdge R630 Owner’s Manual — Supported Processors

  • Dell PowerEdge R630 Owner’s Manual — Memory Specifications

  • Dell PowerEdge R630 Owner’s Manual — Expansion Bus Specifications (PCIe Risers)

  • Dell PowerEdge R630 Owner’s Manual — Drive Specifications

  • Dell PowerEdge R630 Owner’s Manual — Power Supply Specifications

  • Dell PowerEdge R630 Owner’s Manual — Environmental Specifications

  • Dell PowerEdge R630 Configuration Guide (Japanese)

  • Dell PowerEdge R630 Spec Sheet (German)

  • Dell PowerEdge R630 Spec Sheet (French)

Product Overview

The Dell PowerEdge R630 is a two-socket, 1U rack server that delivers performance previously attainable only in 2U servers. It is designed for virtualization environments, large business applications, and transaction-intensive databases. Powered by the latest Intel Xeon E5-2600 v4 product family (and also supporting E5-2600 v3 processors), the R630 features up to 24 DDR4 DIMM slots, extensive local storage options, and up to 3 PCIe 3.0 expansion slots. Its ultra-dense design allows configurations with up to 24 x 1.8-inch SSDs or 10 x 2.5-inch drives, including support for up to four NVMe Express Flash PCIe SSDs. The R630 is positioned as a highly versatile solution for high-density virtualization, in-memory databases, and performance-sensitive workloads such as e-commerce and financial trading .

Technical Specifications

Feature Specification
Form Factor 1U rack server
Processors Up to two Intel Xeon E5-2600 v3 or v4 processors
Processor Socket 2 sockets
Max Cores per Processor Up to 22 cores (E5-2600 v4); up to 18 cores (E5-2600 v3)
Cache 2.5 MB per core; core options: 4, 6, 8, 10, 12, 16, 18, 22
Chipset Intel C610 series
Memory — Type DDR4 RDIMMs and LRDIMMs
Memory — Speed 1866 MT/s, 2133 MT/s, or 2400 MT/s
Memory — Sockets 24 x 288-pin DIMM slots
Memory — Capacity Options RDIMM: 4 GB, 8 GB, 16 GB, 32 GB; LRDIMM: 64 GB
Memory — Max RAM (Dual Processor) LRDIMM: up to 1536 GB; RDIMM: up to 786 GB
Drive Bays — Option 1 Up to 24 x 1.8-inch SATA SSDs (hot-plug)
Drive Bays — Option 2 Up to 10 x 2.5-inch drives (SAS HDD, SATA HDD, Nearline SAS HDD, SAS SSD, SATA SSD)
Drive Bays — Option 3 Up to 8 x 2.5-inch drives (SAS HDD, SATA HDD, Nearline SAS HDD, SAS SSD, SATA SSD)
NVMe Support Up to 4 x Express Flash NVMe PCIe SSDs (with 10 x 2.5-inch configuration)
Max Internal Storage — 24 x 1.8″ Up to 23 TB (via 0.96 TB hot-plug SATA SSDs)
Max Internal Storage — 10 x 2.5″ Up to 18 TB (via 1.8 TB hot-plug SAS HDDs)
Max Internal Storage — 8 x 2.5″ Up to 14 TB (via 1.8 TB hot-plug SAS HDDs)
PCIe Expansion Slots Up to 3 x PCIe 3.0 slots + 1 dedicated PERC slot
Riser 1 PCIe Slots Slot 1: x16, LP, Half Length; Slot 2: x8, LP, Half Length
Riser 2 PCIe Slots Slot 1: x8, LP, Half Length; Slot 1: x16, LP, Half Length
Riser 3 PCIe Slots Slot 2: x16, FH, 3/4 Length; Slot 3: x16, LP, Half Length
RAID Controllers (Internal) PERC S130 (SW RAID), PERC H330, PERC H730, PERC H730P
RAID Controllers (External) PERC H830 (RAID); 12 Gb/s SAS HBA (non-RAID)
Embedded NIC 4 x 1 GbE, or 2 x 1 GbE + 2 x 10 GbE, or 4 x 10 GbE
Power Supplies 495 W AC (Platinum), 750 W AC (Platinum/Titanium), 1100 W AC (Platinum), 1100 W DC, 750 W DC (China only)
Redundant Power Yes (hot-plug redundant PSU)
Internal Dual SD Module Supported (for fail-safe hypervisor)
Systems Management iDRAC8 with Lifecycle Controller; iDRAC8 Express (default); iDRAC8 Enterprise (upgrade); iDRAC Quick Sync
Operating Systems Microsoft Windows Server 2008/2012/R2 (with Hyper-V); Red Hat Enterprise Linux; SUSE Linux Enterprise Server; VMware vSphere ESXi; Citrix XenServer
Hypervisor Support Microsoft Windows Server with Hyper-V; Citrix XenServer; VMware vSphere ESXi
Form Factor Dimensions (W x H x D) 482.3 mm x 42.8 mm x 755.1 mm (24 x 1.8″ / 10 x 2.5″ config); 482.3 mm x 42.8 mm x 700.5 mm (8 x 2.5″ config)
Rack Support ReadyRails II sliding rails (tool-less for 4-post square/round hole racks); optional cable management arm
