Dell PowerEdge T430 Server — Product Information Sheet

Product Overview

The Dell PowerEdge T430 is a two-socket tower server designed for small to medium-sized businesses, remote offices, and enterprise environments requiring a balance of performance, scalability, and quiet operation. It supports up to two Intel Xeon E5-2600 v3 or v4 series processors, up to 12 DDR4 DIMM slots, and flexible storage configurations with up to sixteen 2.5-inch drives or eight 3.5-inch drives. The T430 features six PCIe expansion slots (four Gen3 and two Gen2), dual 1GbE LOMs, and can be rack-mounted in a 5U form factor .

Technical Specifications

Feature Specification
Form Factor Tower (rack-mountable in 5U)
Processor Sockets 2
Supported CPU Intel Xeon E5-2600 v3 and v4 product families
Chipset Intel C610 Series
Internal Interconnect 2 x QPI links at 9.6 GT/s
Cache 2.5 MB per core
Core Options 4, 6, 8, 10, 12, 14 (varies by specific processor model)
Memory Slots 12 x 288-pin DIMM sockets
Memory Type DDR4 Registered DIMMs (RDIMM)
Memory Capacity Options 4 GB single-rank; 8 GB, 16 GB, 32 GB single and dual-rank
Memory Speed 1866 MT/s, 2133 MT/s, or 2400 MT/s (dependent on system profile and processor capability)
Minimum RAM 4 GB (single processor); 8 GB (dual processors, minimum one DIMM per processor)
Maximum RAM 256 GB (single processor); 384 GB (dual processors)
Drive Bays (3.5″) Up to 4 cabled (SATA / Nearline SAS); up to 8 hot-swappable (SATA / Nearline SAS)
Drive Bays (2.5″) Up to 16 hot-swappable (SATA, Nearline SAS, SAS, SATA SSD)
Supported Drive Types SAS, SATA, Nearline SAS, SSD
Optical Drive One optional SATA DVD-ROM or DVD+/-RW (or slim SATA variant)
Tape Drive Up to two optional 5.25-inch tape drives
RAID Controller PERC H730, PERC H730P, PERC H830 (max one internal and one external)
Network Controller 2 x 1GbE LOMs (Broadcom 5720)
PCIe Slots 6 total: Slot 1 (Gen2, x4 link, x8 slot, PCH); Slot 2 (Gen2, x1 link, x1 slot, PCH); Slot 3 (Gen3, x16 link, x16 slot, CPU1); Slot 4 (Gen3, x16 link, x16 slot, CPU1); Slot 5 (Gen3, x8 link, x8 slot, CPU2); Slot 6 (Gen3, x8 link, x8 slot, CPU2)
PCIe Slot Notes Slots 5 and 6 require both processors installed. Expansion cards are not hot-swappable.
Power Supply Options 450 W cabled non-redundant; 495 W, 750 W, 1100 W hot-plug redundant
System Battery CR 2032 3.0-V lithium coin cell
Serial Port DB-9 serial connector
USB Ports USB 2.0 and USB 3.0 ports (front and rear); internal USB 3.0 compatible port
VGA Ports 2 x 15-pin VGA (front and rear on hot-swap chassis); 1 x 15-pin VGA (rear only on cabled chassis)
Internal Dual SD Module 2 optional flash memory card slots (one used at a time for redundancy)
Systems Management IPMI 2.0 compliant; iDRAC8 with Lifecycle Controller (Express standard, Enterprise upgrade)
Dimensions (Tower) Height: 430.3 mm; Width: 218 mm; Depth: 542.2 mm (without bezel)
Rack Dimensions Height: 218 mm; Width: 430.3 mm (without brackets) / 482.40 mm (with brackets); Depth: 538.4 mm (minimum)
