Huawei S3700-52P-PWR-SI-AC – Product Documentation

Name: Huawei S3700-52P-PWR-SI-AC Switch - SunSpike
SKU: S3700-52P-PWR-SI-AC

Product Overview

The Huawei S3700-52P-PWR-SI-AC is a next-generation Layer 3 Ethernet switch designed for enterprise campus networks, small and medium-sized businesses (SMBs), and PoE-powered device deployments. Part of the S3700-SI series, this managed PoE+ switch delivers reliable power and high-speed connectivity to wireless access points, IP cameras, VoIP phones, and other networked devices.

The switch features 48× 10/100 Mbps Fast Ethernet ports with PoE+ support and 4× Gigabit SFP uplink ports, providing scalable fiber expansion for flexible network growth. It comes with a built-in 500W AC power supply and dual power slots for enhanced power redundancy. With a switching capacity of 64 Gbps and a forwarding performance of 13.2 Mpps, the S3700-52P-PWR-SI-AC delivers enterprise-grade performance for demanding network environments.

The switch supports advanced features including VLANs (4K), QoS, ACLs, STP/RSTP/MSTP, IPv4 and IPv6 routing, multicast, and comprehensive security mechanisms. Reliability is enhanced through technologies such as RRPP (ring protection with <50 ms switchover), Smart Link, and SEP. Designed for 24×7 continuous operation, this rack-mountable switch is ideal for office LANs, campus networks, retail, hospitality, and educational environments.

Technical Specifications

Category	Specification
Product Model	S3700-52P-PWR-SI-AC
Product Series	Huawei S3700 Series
Product Type	Managed PoE+ Ethernet Switch
Part Number	02354132

Ports & Interfaces

Category	Specification
Downlink Ports	48 × 10/100BASE-TX Fast Ethernet RJ45 ports with PoE+
Uplink Ports	2 × 100/1000BASE-X SFP ports + 2 × 1000BASE-X SFP ports
Total SFP Uplinks	4 × Gigabit SFP ports
Port Structure	Non-modular

Performance

Category	Specification
Switching Capacity	64 Gbps
Forwarding Performance	13.2 Mpps
Switching Mode	Store-and-forward
MAC Address Table	16K entries
VLANs Supported	4K

PoE & Power

Category	Specification
PoE Standard	IEEE 802.3at (PoE+)
Power Supply	500W built-in AC power module
Power Slots	2 (dual power slots)
Power Consumption	< 880W (PoE: 740W)
Input Voltage	AC 100-240V
Power Supply Type	AC-equipped

Physical Specifications

Category	Specification
Dimensions (W × D × H)	442 mm × 420 mm × 43.6 mm (17.4″ × 16.5″ × 1.7″)
Weight	< 4.3 kg (without power supply)
Heat Dissipation	Forced air cooling
Installation	Rack mounting / desk mounting
Surge Protection	6KV surge protection on service ports

Environmental Specifications

Category	Specification
Operating Temperature	0°C to 50°C

Software & Protocols

Category	Specification
Network Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1d, IEEE 802.1w, IEEE 802.1s
Application Layer	Layer 3
IP Routing	Static routing, RIPv1, RIPv2, ECMP
IPv6 Features	Neighbor Discovery (ND), Path MTU (PMTU), IPv6 ping/tracert/telnet, 6to4 tunnel, ISATAP tunnel, ACLs based on source/destination IPv6 address, Layer 4 ports, or protocol type, MLD v1/v2 snooping
VLAN Features	4K VLANs, Guest VLAN, Voice VLAN, Super VLAN, MUX VLAN, GVRP, VLAN assignment based on MAC/protocol/IP subnet, QinQ, Selective QinQ, 1:1 VLAN mapping, N:1 VLAN mapping
Reliability	RRPP (ring topology, intersecting rings, multi-instance, <50 ms switchover), Smart Link (millisecond-level switchover), STP (802.1d), RSTP (802.1w), MSTP (802.1s), BPDU protection, root protection, loop protection, SEP
Multicast	1K multicast groups, IGMP v1/v2/v3 snooping, IGMP fast leave, Multicast VLAN, multicast replication between VLANs, multicast load balancing, controllable multicast
QoS/ACL	Rate limiting, packet redirection, port-based traffic policing, two-rate three-color CAR, 8 queues per port, WRR/DRR/SP/WRR+SP/DRR+SP scheduling, 802.1p/DSCP re-marking, Layer 2-4 packet filtering
Security	User privilege management, password protection, DoS/ARP/ICMP attack defense, IP-MAC-interface-VLAN binding, port isolation, port security, sticky MAC, blackhole MAC, MAC address learning limit, 802.1x authentication, AAA/RADIUS/HWTACACS/NAC authentication, SSH v2.0, CPU defense, blacklist/whitelist
Management	iStack, MFF, Telnet remote configuration, Auto-Config, virtual cable test (VCT), Ethernet OAM (802.3ah and 802.1ag), SNMP, Web GUI
Stacking	Supported (service port connection)
