Name: Cisco Catalyst WS-C3850-48U-L - SunSpike
SKU: WS-C3850-48U-L

Cisco Catalyst WS-C3850-48U-L – Product Specifications

Category	Details
Product Overview
Manufacturer	Cisco Systems, Inc.
Product Line	Cisco Catalyst 3850 Series
Model	WS-C3850-48U-L
Description	Cisco Catalyst 3850 Stackable 48 10/100/1000 UPOE ports, 1 network module slot, 1100 W power supply, LAN Base feature set
Product Type	Switch – 48 ports – L3 – managed – stackable
Enclosure Type	Desktop, rack-mountable 1U
Status	End-of-Life (EOL) as of October 29, 2020
Ports & Performance
Ports	48 x 10/100/1000 (UPOE)
PoE Budget	800 W
Switching Capacity	176 Gbps
Stacking Bandwidth	480 Gbps
Forwarding Performance (64-byte packets)	460 Mpps
MAC Address Table Size	32000 entries
Jumbo Frame Support	9198 bytes
Memory & Software
RAM	4 GB
Flash Memory	2 GB
Image	LAN Base
Capacity
IPv4 routes	24000
NetFlow entries	48000
Switched virtual interfaces (SVIs)	1000
Expansion / Connectivity
Expansion Slots	1 (total) / 1 (free) x Stacking Module slot
Management Interfaces	1 x RJ-45, 1 x mini-USB Type B, 1 x serial (RS-232) RJ-45
USB Port	1 x USB Type A
Stacking Ports	2 x network stack device
Power
Power Device	Internal power supply (1100 W)
Redundancy	Optional, 1+1 with optional power supply
Voltage	AC 120/230 V (50/60 Hz)
Environmental
Operating Temperature	-5°C to 45°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10 – 95% (non-condensing)
Physical
Dimensions (WxDxH)	44.5 cm x 45 cm x 4.45 cm (approx.)
Weight	8 kg (approx.)
Warranty
Service & Support	Limited lifetime warranty
Compliant Standards
IEEE Standards	802.3, 802.3u, 802.3z, 802.1D, 802.1Q, 802.3ab, 802.1p, 802.3af, 802.3x, 802.3ad (LACP), 802.1w, 802.1x, 802.1s, 802.3at
