Huawei S2700-52P-PWR-EI-AC Switch – Product Documentation

Name: Huawei S2700-52P-PWR-EI-AC Switch - SunSpike
SKU: S2700-52P-PWR-EI-AC

Product Overview

The Huawei S2700-52P-PWR-EI-AC is a fully managed, enterprise-grade Layer 2 Ethernet switch from Huawei’s S2700 Enterprise Switch Series. It is a next-generation energy-saving 100M intelligent switch that utilizes cutting-edge switching technologies and the Huawei Versatile Routing Platform (VRP) to meet the demands of multi-service provisioning and access on Ethernet networks.

This model integrates 48 Fast Ethernet PoE+ ports with 4 Gigabit Ethernet SFP uplink ports, providing high-density access with Power over Ethernet Plus capabilities. The switch supports intelligent stacking (iStack) technology, which virtualizes multiple switches into a single logical device to ease management and configuration, expand system switching capacity, and enhance reliability and scalability.

Designed for enterprise campus networks, small to medium-sized business infrastructures, and industry networks, the S2700-52P-PWR-EI-AC is ideal for IP surveillance, VoIP deployments, and wireless LAN access point powering. It supports flexible VLAN deployment, comprehensive security and QoS policies, and energy-saving technologies. The switch is rack-mountable (1U) and features a built-in AC power module with PoE+ capabilities on all 48 ports.

Technical Specifications

Category	Specification
Model	S2700-52P-PWR-EI-AC
Switch Type	Fully Managed Layer 2 Ethernet Switch
Fixed Downlink Ports	48 × 10/100BASE-T Ethernet PoE+ ports
Uplink Ports	4 × Gigabit SFP ports
Extended Slots	N/A
Power Supply Slots	2
Power Supply (Equipped)	1 × AC power module
Rated Voltage Range	100 V to 240 V AC, 50/60 Hz
Maximum Voltage Range	90 V to 264 V AC, 50/60 Hz
PoE Standard	IEEE 802.3af (PoE) / 802.3at (PoE+)
Total PoE Power Budget	Up to 370W
Switching Capacity	32 Gbps
Packet Forwarding Rate	13.2 Mpps
MAC Address Table Size	8K
VLAN Support	Up to 4K VLANs, IEEE 802.1Q compliance, port-based VLAN assignment, MAC address-based assignment, port-based QinQ
IPv4 Routing	Static routing
IPv6 Features	IPv6 protocol support, static IPv6 routes, MLD v1/v2 snooping
Multicast	MVLAN, controllable multicast, IGMP v1/v2/v3 snooping, port-based rate limiting for multicast packets
Reliability	STP (IEEE 802.1d), RSTP (IEEE 802.1w), MSTP (IEEE 802.1s), RRPP topology and RRPP multi-instance
QoS	Port-based rate limiting, flow-based rate limiting, 4 or 8 queues of different priorities on each port, mapping between 802.1p priorities and queues, SP, WRR, and SP+WRR algorithms
Security & Access Features	802.1x authentication, limit on number of users per interface, storm suppression, IP Source Guard, AAA authentication, RADIUS authentication, TACACS+ authentication, MAC address authentication, MAC bypass authentication, DHCP snooping, port isolation, sticky MAC, packet filtering based on MAC addresses, suppression of multicast/broadcast/unknown unicast packets, limit on number of learned MAC addresses, CPU defense, DHCP relay
Surge Protection	Service ports: 7kV
Long-term Operating Temperature	–5°C to +50°C
Relative Humidity	10% to 90% (non-condensing)
Dimensions (W × D × H)	442.0 mm × 420.0 mm × 43.6 mm
Weight	≤ 6.5 kg
