Huawei S2700-9TP-SI-AC – Product Documentation

Name: Huawei S2700-9TP-SI-AC Switch - SunSpike
SKU: S2700-9TP-SI-AC

Product Overview

The Huawei S2700-9TP-SI-AC is a next-generation energy-saving intelligent Layer 2 Gigabit Ethernet switch designed for enterprise access networks. Part of the S2700 series, this switch delivers reliable 100Mbps access with Gigabit uplink capabilities, making it an ideal solution for small to medium-sized businesses, campus networks, and branch office deployments.

The switch features a compact, non-modular chassis with 9 ports total: eight 10/100BASE-TX Ethernet ports for user access, one 10/100/1000BASE-T Ethernet port, and one multiplexed Gigabit Combo SFP port that provides flexible uplink connectivity. The Combo port consists of both an optical Ethernet port and an electrical Ethernet port on the panel, with only one active at a time—offering deployment flexibility for fiber or copper uplinks.

With a switching capacity of 32 Gbps and a packet forwarding rate of 2.7 Mpps, the S2700-9TP-SI-AC delivers robust performance for everyday enterprise traffic. The switch supports a wide range of advanced features including VLAN (up to 4K VLANs), Quality of Service (QoS) with multiple queue scheduling algorithms, IGMP snooping for multicast management, and comprehensive network management capabilities via CLI, Telnet, SNMP, and web-based interfaces.

Security is addressed through AAA authentication, RADIUS and HWTACACS+ support, port isolation, broadcast/multicast/unknown-unicast storm suppression, and CPU protection. The switch also features 6KV surge protection for enhanced reliability in diverse operating environments.

Technical Specifications

Category	Specification
General
Product Type	Gigabit Ethernet Switch
Application Layer	Layer 2
Switching Capacity	32 Gbps
Packet Forwarding Rate	2.7 Mpps
MAC Address Table	8K entries
Switching Mode	Store-and-Forward
Ports
Port Structure	Non-modular
Total Ports	9
Fixed Ports	8 × 10/100BASE-TX Ethernet ports
Uplink Ports	1 × 10/100/1000BASE-T Ethernet port + 1 × multiplexed Gigabit Combo SFP
Console Port	1 × Console port
Transmission Mode	Full-duplex / Half-duplex auto-negotiation
Standards
Network Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1Q, IEEE 802.1d, IEEE 802.1X
VLAN
VLAN Support	IEEE 802.1Q (VLAN), up to 4K VLANs supported
VLAN Types	Port-based VLAN
Quality of Service (QoS)
Queue Scheduling	SP (Strict Priority), WRR (Weighted Round Robin), SP+WRR
Priority Queues	4 or 8 priority queues per port
QoS Features	Egress port rate limiting; 802.1p-based packet-to-queue mapping
Multicast
Multicast Management	IGMP v1/v2/v3 Snooping
Multicast Features	Port-based multicast flow rate limiting; bundled port multicast load balancing
Network Management
Management Interfaces	CLI, Telnet, SNMP V1/V2C/V3, RMON, Web-based management
Stacking	Stackable
Additional Management	Auto-configuration; HGMP V2 cluster management; SSH V2
Security
Authentication	AAA, RADIUS, HWTACACS+
Security Features	Port isolation; broadcast/multicast/unknown-unicast storm suppression; CPU protection; DHCP Snooping; 802.1X; Dynamic ARP Inspection; IP Source Guard; MAC address filtering; Sticky MAC
Power
Power Supply	AC 100-240V, 50/60Hz
Maximum Power Consumption	< 12.8W
Physical
Dimensions (W × D × H)	250 × 180 × 43.6 mm
Weight	< 1.4 kg
Environmental
Operating Temperature	0°C to 45°C
Storage Temperature	-5°C to 55°C
Operating Humidity	5% to 95% (non-condensing)
Storage Humidity	10% to 90% (non-condensing)
Reliability
Surge Protection	6KV lightning protection
Flash Memory	64 MB
