Huawei S2700-9TP-EI-AC – Product Documentation

Name: Huawei S2700-9TP-EI-AC Switch - SunSpike
SKU: S2700-9TP-EI-AC

Product Overview

The Huawei S2700-9TP-EI-AC is a next-generation energy‑efficient intelligent 100M Ethernet access switch designed for enterprise networks. As an Enhanced (EI) model within the S2700 Series, it combines flexible VLAN deployment, comprehensive security policies, quality of service (QoS) control, and green energy‑saving technologies to help enterprises build next‑generation IT networks.

The switch delivers 8 x 10/100BASE‑TX Ethernet ports for downlink access and 1 x dual‑purpose Gigabit Combo port (10/100/1000BASE‑T + 100/1000BASE‑X) for uplink connectivity, providing flexible network deployment options. With a switching capacity of 32 Gbps and a forwarding performance of 2.7 Mpps, it offers reliable packet forwarding for small to medium‑sized enterprise access scenarios.

The S2700‑9TP‑EI‑AC supports a comprehensive suite of management features including CLI, Telnet, SNMP v1/v2c/v3, RMON, SSH v2, and web‑based management, enabling efficient device operation and maintenance. Its fan‑free design ensures silent operation, making it suitable for office and quiet environments.

Technical Specifications

Category	Specification
Model	S2700-9TP-EI-AC
Product Type	Gigabit Ethernet switch / Intelligent 100M Ethernet access switch
Application Layer	Layer 2 / Layer 3
Switching Capacity	32 Gbps
Forwarding Performance	2.7 Mpps
MAC Address Table	8K entries
Switching Mode	Store‑and‑forward
Port Structure	Non‑modular
Total Ports	9 ports (8 x FE + 1 x GE Combo)
Downlink Ports	8 x 10/100BASE‑TX Ethernet ports
Uplink Ports	1 x Combo port (10/100/1000BASE‑T + 100/1000BASE‑X)
Transmission Mode	Full‑duplex / Half‑duplex auto‑negotiation
Transmission Rate	10/100/1000 Mbps
VLAN	Supports IEEE 802.1Q VLAN, up to 4K active VLANs; port‑based VLAN assignment
QoS	Port‑based rate limiting; 4 or 8 priority queues per port; 802.1p priority mapping; SP, WRR, and SP+WRR scheduling algorithms
Multicast	IGMP v1/v2/v3 snooping; port‑based multicast rate limiting
IPv4 Routing	Static routing
IPv6 Features	IPv6 protocol support; static IPv6 routes; MLD v1/v2 snooping
Reliability	STP (IEEE 802.1d), RSTP (IEEE 802.1w), MSTP (IEEE 802.1s), RRPP
Security	802.1x authentication; AAA, RADIUS, TACACS+; port isolation; DHCP snooping; storm suppression; CPU protection
Network Management	CLI configuration; Telnet; SNMP v1/v2c/v3; RMON; SSH v2; web‑based management; auto‑configuration; HGMP cluster management
Network Standards	IEEE 802.1D, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab
Stacking	Stackable
Power Supply	AC 100‑240V, 50/60 Hz
Maximum Power Consumption	< 14.5 W
Flash Memory	16 MB
RAM	64 MB
Dimensions (W × D × H)	250 × 180 × 43.6 mm (9.84 × 7.09 × 1.72 in)
