Huawei OceanStor Dorado 6000 V3 Product Documentation
Product Overview
The Huawei OceanStor Dorado 6000 V3 is a high-end, all-flash storage system purpose-built for mission-critical enterprise services . As part of Huawei’s fourth-generation all-flash array family, it is designed to fully leverage SSD media to deliver exceptional performance with sub-millisecond latency, while maintaining consistent responsiveness even when data reduction features are enabled .
The system employs a native flash-optimized architecture with intelligent multi-core processors and proprietary FlashLink® technology. This enables the Dorado 6000 V3 to achieve up to 4 million IOPS with a consistent latency of approximately 500 microseconds (0.5 ms) . In SPC-1 benchmark testing, the system demonstrated 1,000,560 SPC-1 IOPS™ with an overall response time of 0.380 ms, showcasing its industry-leading performance capabilities .
The Dorado 6000 V3 features a grid-based, scale-out architecture supporting up to 16 controllers in an active-active configuration with fully redundant design. This architecture, combined with the HyperMetro gateway-free active-active solution, delivers 99.9999% availability and enables seamless upgrades to two-data-center-three-site disaster recovery configurations .
For capacity optimization, the system incorporates inline deduplication and compression technologies (SmartDedupe and SmartCompression), delivering up to 5:1 data reduction rates and reducing OPEX by up to 75% . The array supports both SAN and NAS protocols within a unified storage framework, making it suitable for diverse enterprise workloads including databases, virtual desktop infrastructure (VDI), virtual server environments (VSI), and SAP HANA deployments .
The Dorado 6000 V3 is backed by Huawei’s extensive storage R&D heritage, with the company developing its own SSDs to ensure deep integration between hardware and firmware for optimal performance and reliability .
Product Specifications
| Category | Specification |
|---|---|
| Model | Huawei OceanStor Dorado 6000 V3 |
| Product Type | Enterprise All-Flash Storage Array (SAN/NAS Unified Storage) |
Controller & Processing
| Category | Specification |
|---|---|
| Maximum Controllers | Up to 16 controllers in active-active scale-out architecture |
| Storage Processors | Multi-core processors |
| System Cache (per system) | 1,024 GB to 8,192 GB (1 TB – 8 TB) |
Connectivity & Protocols
| Category | Specification |
|---|---|
| Supported Storage Protocols | FC, iSCSI, InfiniBand, HTTP, FTP |
| Front-end Port Types | 8 Gbps/16 Gbps Fibre Channel, 10GE iSCSI, 56 Gbps InfiniBand |
| Back-end Port Types | SAS 3.0 (single port 4 x 12 Gbps); PCIe 3.0 (two ports 8 x 8 Gbps) |
| Maximum Front-end Ports (per controller) | 28 ports |
Storage Capacity
| Category | Specification |
|---|---|
| Maximum SSDs | Up to 2,400 SAS SSDs |
| SSD Types | 600 GB / 900 GB / 1.8 TB / 3.6 TB / 7.68 TB SAS SSD (2.5″) |
| Maximum Hosts Supported | 8,192 |
| Maximum LUNs | 16,384 |
Data Protection & RAID
| Category | Specification |
|---|---|
| RAID Support | RAID 5, RAID 6, RAID-TP (Triple Parity – tolerates up to 3 concurrent disk failures) |
Software & Management
| Category | Specification |
|---|---|
| Value-added Software | SmartDedupe (inline deduplication), SmartCompression (inline compression), SmartVirtualization, SmartMigration, SmartThin (thin provisioning), HyperReplication (remote replication), HyperSnap (snapshots), HyperMetro (array active-active) |
| Storage Management Software | DeviceManager, UltraPath (multipathing), eService (remote maintenance management) |
| Virtualization Support | Huawei FusionSphere, VMware (VAAI/VASA/SRM), XenServer, Hyper-V; integration with vSphere and vCenter |
| Supported Operating Systems | AIX, HP-UX, Solaris, Linux, Windows |
Physical Specifications
| Category | Specification |
|---|---|
| Controller Enclosure Dimensions | 130.5 × 447 × 750 mm (3U) |
| Disk Enclosure Dimensions | 86.1 × 447 × 488 mm (2U) |
| Controller Enclosure Weight | ≤ 50 kg |
| Disk Enclosure Weight | ≤ 20 kg |
Power & Environmental
| Category | Specification |
|---|---|
| Power Supply | AC 200-240V; DC 192-288V or -48-(-60)V |
| Typical Power Consumption (Controller) | 936 W |
| Typical Power Consumption (Disk Enclosure) | 240 W |
| Operating Temperature (Altitude < 1,800 m) | 5°C to 40°C |
| Operating Temperature (Altitude 1,800-3,000 m) | 5°C to 35°C |
| Operating Humidity | 5% to 95% RH (non-condensing) |
