Huawei OceanStor 5500 V3
Huawei OceanStor 5500 V3
Enterprise stock · tested · export documentation available
Huawei OceanStor 5500 V3 Product Datasheet
Product Overview
The Huawei OceanStor 5500 V3 is a mid-range unified storage system designed for enterprise-class applications in the cloud era. Built on Huawei’s convergence architecture, it integrates SAN and NAS capabilities into a single platform while optimizing for flash storage performance. The system delivers sub-1 ms latency in all-flash configurations and supports a maximum of 8 controllers for horizontal scalability.
Key Capabilities:
-
Unified Storage: Native support for block (FC, FCoE, iSCSI) and file (NFS, CIFS) protocols
-
Convergence: SAN/NAS convergence, SSD/HDD convergence, and heterogeneous device virtualization
-
Performance: Achieves 40,000–60,000 IOPS per system in real-world deployments
-
Availability: Active-active controller architecture with HyperMetro for continuous service
-
Scalability: Scales to 8 controllers, 1 TB cache, and 7.5 PB storage capacity
The OceanStor 5500 V3 is widely deployed in government, finance, telecommunications, energy, and media sectors for mission-critical workloads including OLTP/OLAP databases, file sharing, and cloud computing.
Technical Specifications
| Parameter | Specification |
|---|---|
| Storage Processor | Multi-core multi-processor group |
| System Cache | 48 GB – 384 GB (some sources indicate up to 512 GB) |
| Maximum Controllers | 8 |
| Supported Storage Protocols | Fibre Channel, FCoE, iSCSI, InfiniBand, NFS, CIFS, HTTP, FTP |
| Front-End Port Types | 1 Gbit/s Ethernet, 10 Gbit/s FCoE, 10 Gbit/s TOE, 16 Gbit/s Fibre Channel, 56 Gbit/s InfiniBand |
| Back-End Port Type | SAS 3.0 (each port supporting 4 × 12 Gbit/s) |
| Maximum Disk Positions | 750 |
| Disk Types | SSD, SAS, NL-SAS |
| Supported RAID Levels | 0, 1, 3, 5, 6, 10, 50 |
| Maximum Snapshots (LUN) | 1,024 |
| Maximum LUNs | 4,096 |
| Maximum Single File Capacity | 256 TB |
| Power Supply | AC: 100–127 V or 200–240 V; DC: 192–288 V or –48 to –60 V |
| Dimensions (2U Controller Enclosure) | 86.1 mm × 447 mm × 750 mm |
| Weight | ≤ 37 kg |
Data Protection Software
| Software | Function |
|---|---|
| HyperSnap | Snapshot |
| HyperCopy | LUN copy |
| HyperClone | Clone |
| HyperMirror | Volume mirror |
| HyperReplication | Remote replication |
| HyperLock | WORM (Write Once Read Many) |
Storage Management Software
| Software | Function |
|---|---|
| UltraPath | Multipathing management |
| Cloud Service | Remote maintenance and management |
| ReplicationDirector | Disaster recovery management |
