Huawei OceanStor 2200 V3 – Product Documentation
Product Overview
The Huawei OceanStor 2200 V3 is an entry-level, flash-optimized enterprise storage system designed to meet the performance requirements of small- and medium-sized businesses (SMBs). It supports Online Transaction Processing (OLTP) and Online Analytical Processing (OLAP) for enterprise databases, as well as workloads including Exchange, server virtualization, and video surveillance services .
Built with a 16 Gbit/s Fibre Channel host port, PCIe 3.0 internal bus, and 12 Gbit/s SAS 3.0 disk interfaces, the system delivers enterprise-class data transmission speeds. Its flash-oriented design ensures SSD performance with sub-1ms latency . The storage system converges SAN and NAS protocols to support both block and file services on a single device, simplifying IT architecture and reducing capital expenditure .
The OceanStor 2200 V3 features the Smart and Hyper series of data management software, providing intelligent resource optimization and comprehensive data protection. With the SmartConfig tool, resources can be allocated in minutes through a simple three-step process, eliminating the need for specialized storage expertise . The system supports heterogeneous virtualization, consolidating storage resources from mainstream products for unified management and allocation .
Technical Specifications
| Category | Specification |
|---|---|
| Model | OceanStor 2200 V3 |
| System Cache (Dual Controllers) | 16 GB or 32 GB |
| Maximum Number of Controllers | 2 |
| Maximum Number of Disks | 300 |
| Maximum Storage Capacity | 256 TB |
| Disk Types | SSD, SAS, NL-SAS |
| Supported Storage Protocols | Fibre Channel, FCoE, iSCSI, NFS, CIFS, HTTP, FTP |
| Front-End Port Types | 1/10 Gbit/s Ethernet, 10 Gbit/s FCoE, 8/16 Gbit/s Fibre Channel |
| Back-End Port Type | SAS 3.0 (each port supporting 4 x 12 Gbit/s) |
| Maximum Hot-Swappable I/O Modules per Controller | 1–2 (varies by configuration) |
| Maximum Front-End Host Ports per Controller | 12–24 (varies by configuration) |
| Supported RAID Levels | 0, 1, 3, 5, 6, 10, 50 |
| Power Supply | AC: 100–240V |
| Dimensions (H x W x D) | 2U Controller Enclosure: 86.1 x 447 x 488 mm 2U Disk Enclosure: 86.1 x 447 x 490 mm 4U Disk Enclosure: 175 x 447 x 490 mm |
| Weight | 2U Controller Enclosure: < 24 kg 2U Disk Enclosure: < 20 kg 4U Disk Enclosure: < 44 kg |
| Operating Temperature | 5°C to 40°C (at -60m to 1800m altitude); derates by 1°C per 220m above 1800m up to 3000m |
| Operating Humidity | 5% RH to 90% RH |
Software Features
| Category | Software Suite |
|---|---|
| Data Protection & Cloning | HyperSnap (snapshot), HyperCopy (LUN copy), HyperClone (clone), HyperMirror (volume mirror), HyperReplication (remote replication), HyperVault (integrated backup), HyperLock (WORM) |
| Resource Efficiency & Optimization | SmartQoS (intelligent QoS control), SmartTier (intelligent storage tiering), SmartCache (intelligent SSD caching), SmartThin (intelligent thin provisioning), SmartMotion (intelligent data migration), SmartMigration (LUN migration), SmartErase (data destruction) |
| Management & Virtualization | UltraPath (multipathing management), BCManager (disaster recovery management), DeviceManager (single-device management), eSight (multi-device management), SmartConfig (easy configuration tool), Heterogeneous Virtualization, Block Virtualization |
| Virtualization Platform Support | FusionSphere, VMware, XenServer, Hyper-V; supports VMware VAAI/VASA/SRM |
