Dell PowerEdge T30 — Product Data Sheet

Overview

The Dell PowerEdge T30 is a compact mini-tower server designed for small office and home office environments. It consolidates business data, media files, and productivity applications onto a single, affordable platform. The T30 is built around the Intel C236 chipset and supports a single Intel Xeon E3-1200 v5, Intel Core i3, or Intel Pentium processor . It offers up to 64 GB of DDR4 memory, flexible storage configurations with support for up to six SATA drives, and a mix of PCIe and legacy PCI expansion slots. With ECC memory support and software RAID capability, the T30 delivers essential data protection for light workloads without the complexity or cost of an enterprise-class rack server .

Specifications

Feature Specification
Form Factor Mini-tower
Dimensions (H × W × D) 359.9 mm × 175 mm × 434.85 mm (14.17″ × 6.89″ × 17.12″)
Processor Options 1 × Intel Xeon E3-1200 v5 processor OR Intel Core i3 series processor OR Intel Pentium processor
Validated Processors Intel Xeon E3-1225 v5; Intel Pentium G4400; Intel Core i3-6100
Processor Socket 1 socket
Cache 8 MB (Xeon E3-1225 v5); 3 MB (Pentium G4400)
Chipset Intel C236
Memory Slots 4 × 288-pin UDIMM slots
Memory Type DDR4 2133 MT/s (ECC) or 2400 MT/s (Non-ECC), single-rank or dual-rank
Memory Capacity per DIMM 4 GB, 8 GB, 16 GB
Minimum RAM 4 GB
Maximum RAM 64 GB
Memory Note ECC DIMM recommended for critical applications; Non-ECC supported only in selected countries
Hard Drive Configurations Six drives: up to 4 × 3.5″ internal cabled SATA HDD/SSD + 2 × 2.5″ internal cabled SATA HDD/SSD (optional)
Four drives: up to 4 × 3.5″ internal cabled SATA HDD/SSD
Three drives: up to 3 × 3.5″ internal cabled SATA HDD/SSD + 1 × optical drive (optional)
Storage Controller (Software RAID) Intel Rapid Storage Controller 12.X — RAID 0 and RAID 1 only
Storage Controller (Hardware RAID) Optional storage controller card (P-Card: non-Dell, 2-port SATA 6 Gbps PCI Express SATA controller card) supports up to 4 SATA devices
Optical Drive 9.5 mm slim SATA DVD-ROM or DVD+/-RW (optional)
PCIe Slot 1 Full height, half length, x16 link (Gen 3) — Processor-connected
PCIe Slot 3 Full height, half length, x4 link (Gen 3) — PCH-connected
PCIe Slot 4 Full height, half length, x4 link (wired as x16 slot) — PCH-connected
PCI Slot 2 Full height, half length, 32/33 PCI — PCIe/PCI bridge-connected
PCIe Power Limit Each PCIe expansion card consumption less than 25 W
Embedded NIC Intel I219-LM Gigabit Ethernet LAN 10/100/1000, 1-port
Power Supply 290 W AC, cabled, auto-ranging (100–240 V AC, 50–60 Hz)
System Battery CR 2032 3.0-V lithium coin cell
Systems Management Intel AMT 11.0 (only on Intel Xeon CPU configurations)
