Dell PowerEdge T140 Tower Server — Product Overview & Specifications

Product Overview

The Dell EMC PowerEdge T140 is an entry-level tower server designed for small businesses, remote offices, and home offices requiring reliable performance with quiet operation. It features a single Intel processor socket, supporting Intel Xeon E-2100/E-2200 series, Core i3, Pentium, and Celeron processors. The system accommodates up to 64GB of DDR4 UDIMM memory across four DIMM slots and supports up to four 3.5-inch cabled SAS or SATA drives. With four PCIe 3.0 expansion slots and integrated Dell Remote Access Controller 9 (iDRAC9) for management, the T140 delivers essential server capabilities in a compact tower form factor suitable for collaboration, file/print, mail/messaging, and point-of-sale workloads.

Specifications

Category Specification
Form Factor Tower
Processors Supported Intel Xeon E-2200 product family; Intel Xeon E-2100 product family; Intel Core i3 9100; Intel Core i3 8100; Intel Pentium G5420; Intel Pentium G5500; Intel Celeron G4930; Intel Celeron G4900
Processor Socket Count 1
Chipset Intel C246
Memory Slots 4 x 288-pin DIMM slots
Memory Type DDR4 UDIMM (ECC or non-ECC)
Memory Speed 2666 MT/s, 2400 MT/s, 2133 MT/s (3200 MT/s UDIMM compatible from BIOS 2.5.1, downshifts to 2666 MT/s)
Memory Capacity (per DIMM) 8GB (single rank or dual rank), 16GB
Minimum RAM 8GB
Maximum RAM 64GB
Drive Bays Up to 4 x 3.5-inch cabled SAS or SATA drives
Supported Drive Types 3.5-inch Enterprise SATA 7.2K HDD; 3.5-inch Near Line SAS 7.2K HDD; 3.5-inch 7.2K SATA Entry Drives
Optional Optical Drive 1 x slim ODD 9.5mm
Embedded Storage Controller PERC S140 (Software RAID; supports RAID 0, 1, 5, 10)
Optional Storage Controllers PERC H330 (RAID); PERC H730P (RAID); HBA330 (Non-RAID); 12Gb/s SAS HBA (Non-RAID, external)
Boot Optimized Storage (BOSS) Optional: 1 x or 2 x M.2 240GB modules (RAID 1 or No RAID for dual config; No RAID only for single config)
PCIe Slots 4 x PCIe 3.0 slots (all full height, half length)
PCIe Slot 1 x8 link in x8 slot (Processor-attached)
PCIe Slot 2 x8 link in x16 slot (Processor-attached)
PCIe Slot 3 x1 link in x1 slot (PCH-attached)
PCIe Slot 4 x4 link in x8 slot (PCH-attached)
Power Supply 365W AC cabled (Gold efficiency)
Cooling Fans 1 x system fan (rear); 1 x processor fan (on heatsink)
Management iDRAC9 (dedicated Gigabit port, iDRAC Direct microUSB)
Remote Management iDRAC9 with hardware/firmware inventory, alerting, email alerts, electronic licensing
