Huawei CloudEngine S5736-S48S4XC
S5736-S48S4XC
Enterprise stock · tested · export documentation available
Huawei CloudEngine S5736-S48S4XC Product Documentation
Product Overview
The Huawei CloudEngine S5736-S48S4XC is a next-generation standard all-optical Gigabit Ethernet access switch from Huawei’s CloudEngine S5736-S series . Developed on Huawei’s high-performance next-generation hardware and the Versatile Routing Platform (VRP), this switch delivers enhanced Layer 3 features, simplified operations and maintenance (O&M), flexible Ethernet networking, and mature IPv6 capabilities .
The switch features a compact 220 mm depth design supporting desktop, wall, and rack mounting, with a front-access power supply that facilitates easy maintenance and management . It supports intelligent O&M through Telemetry real-time data collection, enabling proactive network issue detection when paired with Huawei’s CampusInsight network analyzer .
With its all-optical architecture and flexible Right-To-Use (RTU) licensing model, the device allows smooth upgrade of downlink ports from GE to 10GE, protecting customer investment and ensuring network scalability .
Product Specification Table
| Parameter | Specification |
|---|---|
| Model | CloudEngine S5736-S48S4XC |
| Fixed Ports | 48 x GE SFP ports, 4 x 10 GE SFP+ ports |
| Expansion Slot | 1 x extension slot |
| Forwarding Performance | 240 Mpps |
| Switching Capacity | 496 Gbit/s / 1.36 Tbit/s (device/system) |
| MAC Address Table Size | 32,000 entries |
| VLAN Features | 4094 VLANs; Guest VLAN, Voice VLAN; GVRP; MUX VLAN; VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports; 1:1 and N:1 VLAN Mapping |
| MAC Features | IEEE 802.1d compliance; Automatic MAC address learning and aging; Static, dynamic, and blackhole MAC entries; Source MAC address-based packet filtering |
| IP Routing | Static route, RIPv1/v2, RIPng, OSPF, OSPFv3, ECMP, IS-IS, IS-ISv6, BGP, BGP4+ |
| Layer 2 Redundancy Protocols | STP, RSTP, MSTP, ERPS, SEP |
| Multicast | IGMPv1/v2/v3, PIM-DM, PIM-SM, PIM-SSM, MSDP, RPF |
| Super Virtual Fabric (SVF) | Plug-and-play of SVF clients; Automatic software package and patch loading; One-click service configuration delivery; Independent SVF client running |
| Stacking | iStack supported |
| Security & Access Control | ACL (1000 rules); 802.1X, MAC, Portal authentication; DHCP Snooping; IP Source Guard; Dynamic ARP Inspection (DAI); DoS protection; MACsec |
| QoS | 8 queues per port; WRR, DRR, SP, WRR+SP, DRR+SP queue scheduling; Traffic policing and shaping; Priority re-marking |
| Management & O&M | Telemetry; SNMP; RMON; Syslog; Web/CLI management; Console port (RJ-45); Management port (1000Base-T) |
| Interoperability | VBST (compatible with PVST/PVST+/RPVST); LNP (similar to DTP); VCMP (similar to VTP) |
| Power Supply | Dual hot-swappable power modules (1+1 redundancy); AC input: 100-240V AC, 50/60Hz; DC input: 48-60V DC |
| Max Power Consumption | 100W |
| Cooling | Active cooling with 2 fan modules; intelligent speed regulation |
| Dimensions (H x W x D) | 43.6 mm x 442 mm x 420 mm (1U) |
| Weight | 8.6 kg (with packaging) |
| Operating Temperature | -5°C to 45°C (long-term); -5°C to 50°C (short-term) |
| Storage Temperature | -40°C to 70°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Noise Level | 49.9 dBA |
| Surge Protection (Power Port) | Differential mode ±6 kV, Common mode ±6 kV |
