Huawei CloudEngine S2326TP-PWR-EI-AC – Product Documentation

Name: Huawei CloudEngine S2326TP-PWR-EI-AC - Refurbished & Tested - SunSpike
Brand: HUAWEI
SKU: S2326TP-PWR-EI-AC

Product Overview

The Huawei CloudEngine S2326TP-PWR-EI-AC is a managed Layer 2 access switch from the S2300-EI series, designed for enterprise campus networks requiring Power over Ethernet (PoE) capabilities . This model features 24 Fast Ethernet ports with PoE support and 2 Gigabit combo ports for uplink flexibility. With a total power consumption of under 868W and PoE budget of 740W, it is well-suited for powering IP phones, wireless access points, and surveillance cameras directly through Ethernet cables .

The switch delivers a backplane switching capacity of 32 Gbit/s and forwarding performance of 8.8 Mpps . It supports comprehensive Layer 2 features including VLAN (up to 4094 VLANs), QoS with multiple queue scheduling algorithms, IGMP snooping for multicast optimization, and robust security features such as port isolation and CPU protection . Management options include CLI, Telnet, SSH v2, SNMP, and Web-based management, making it adaptable to various operational environments .

Technical Specifications

Category	Specification
Fixed Ports	24 × 10/100Base-T ports + 2 × 10/100/1000Base-T or 100/1000Base-X combo ports
Power Supply	Fixed AC power supply (Rated: 100V–240V, 50/60Hz; Max: 90V–264V, 50/60Hz)
Processor	Dominant frequency: 200 MHz
DDR Memory	64 MB
Flash Memory	16 MB
Backplane Switching Capacity	32 Gbit/s
Forwarding Performance	8.8 Mpps
MAC Address Table	Supports up to 8K MAC address entries; supports manual addition/deletion, aging time configuration, MAC learning limits based on port or aggregation group, and blackhole MAC addresses
VLAN Features	Supports IEEE 802.1Q VLAN and up to 4094 VLANs; supports port-based VLAN
QoS	Port rate limit and traffic rate limit; 4 priority queues per port; 802.1p mapping; supports SP, WRR, and SP+WRR scheduling algorithms
IPv6 Features	Supports IPv6 host functions; supports static route configuration
Multicast	Supports IGMP v1/v2/v3 snooping; multicast load sharing among bundled ports; port-based multicast rate limit and traffic statistics
Port Mirroring	Supports 1:1 or N:1 port mirroring; supports packet forwarding on an observing port
Security	Supports port isolation; suppression of multicast, broadcast, and unknown unicast packets; CPU protection
Surge Protection	6 KV per port (standard); 15 KV per port with additional surge protection device
Management & Maintenance	iStack; automatic configuration; CLI; Telnet; SNMP v1/v2/v3; RMON; HGMP v2; SSH v2; Web management; GVRP
Dimensions (W × D × H)	442 mm × 420 mm × 43.6 mm
Weight	< 4 kg
Power Consumption	< 868 W total (PoE power budget: 740 W)
Operating Environment	Long-term temperature: 0°C to 50°C; Short-term temperature: –5°C to 55°C; Relative humidity: 10% to 90% (non-condensing)
