Huawei CloudEngine S2318TP-EI-DC Switch – Product Documentation
Product Overview
The Huawei CloudEngine S2318TP-EI-DC (formerly Quidway S2318TP-EI-DC) is a Layer 2 carrier-class access Ethernet switch designed for enterprise intranets and IP Metropolitan Area Networks . It delivers reliable, secure, and efficient network access with intelligent service support for VLAN, QoS, and advanced security protocols .
This switch is equipped with a fixed DC power supply module (-48V to -60V DC), making it particularly suitable for environments where DC power infrastructure is preferred or required, such as telecommunications base stations, data rooms, and critical facilities . The compact 1U form factor enables efficient deployment in space-constrained wiring closets and equipment cabinets.
The S2318TP-EI-DC provides 16 Fast Ethernet ports for user access and 2 Gigabit combo ports (RJ45/SFP) for uplink connectivity, delivering a cost-effective access switching solution for small to medium-sized enterprise networks, government networks, and industrial environments .
Technical Specifications
| Category | Parameter | Specification |
|---|---|---|
| General | Product Type | Carrier-class Access Switch |
| Application Layer | Layer 2 | |
| Switching Capacity | 32 Gbps | |
| Port Switching Capacity | 7.2 Gbit/s | |
| Forwarding Performance | 5.4 Mpps | |
| MAC Address Table | 8K entries | |
| Switching Mode | Store-and-forward | |
| Processor Frequency | 200 MHz | |
| DDR Memory | 64 MB | |
| Flash Memory | 16 MB | |
| Ports | Port Structure | Non-modular |
| Fixed Ports | 16 × 10/100Base-TX ports | |
| Uplink Ports | 2 × 10/100/1000Base-T or 100/1000Base-X combo ports (RJ45/SFP) | |
| Total Ports | 18 | |
| Transmission Mode | Full-duplex / Half-duplex auto-negotiation | |
| Standards | Networking Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1Q |
| VLAN Features | VLAN Support | Up to 4,096 VLANs based on IEEE 802.1Q |
| VLAN Types | Port-based VLAN, MAC-based VLAN | |
| VLAN Switching | Basic QinQ, 1:1 VLAN switching, N:1 VLAN switching | |
| QoS | Queue Support | 4 priority queues per port |
| Scheduling Algorithms | SP, WRR, SP+WRR | |
| Traffic Classification | Based on source/destination MAC, source/destination IP, Layer-4 port, protocol type, VLAN ID, Ethernet frame protocol, CoS | |
| Traffic Policing | Port rate limit and flow rate limit | |
| Multicast | IGMP Snooping | IGMP v1/v2/v3 snooping |
| Multicast Features | Port-based multicast rate limiting and traffic statistics, multicast load sharing | |
| IPv6 | IPv6 Support | IPv6 host functions, static routes, IPv6 ACL, MLD v1/v2 snooping |
| Security | Authentication | 802.1X, AAA, RADIUS, HWTACACS+, NAC |
| Access Control | IP-MAC-port-VLAN binding, port isolation, port security, Sticky MAC | |
| Attack Protection | Dynamic ARP inspection, IP Source Guard, MAC address filtering | |
| Traffic Control | Broadcast/multicast/unknown unicast storm suppression, MAC address learning limit | |
| CPU Protection | CPU protection function | |
| Management | Management Interfaces | CLI, Telnet, SSH v2, Web-based management |
| Network Management | SNMP v1/v2/v3, RMON, HGMP v2, GVRP | |
| Stacking | Stackable (iStack supported) | |
| Auto-configuration | Supported | |
| Power | Power Supply Type | Fixed DC power module |
| Rated Voltage | -48V to -60V DC | |
| Maximum Voltage Range | -36V to -72V DC | |
| Maximum Power Consumption | < 14.5W | |
| Surge Protection | Port Surge Protection | 6 KV per port (15 KV with external protection device) |
| Physical | Dimensions (W×D×H) | 442 × 220 × 43.6 mm (1U) |
| Weight | < 2.4 kg | |
| Environmental | Operating Temperature | 0°C to 50°C (long-term) |
| Short-term Temperature | -5°C to 55°C | |
| Storage Temperature | -5°C to 55°C | |
| Operating Humidity | 10% to 90% (non-condensing) | |
| Storage Humidity | 10% to 90% (non-condensing) |
