Product Overview

The Huawei CloudEngine CE8875-24BQ8DQ is a next‑generation, high‑density 200GE access switch designed for modern data centers, providing 400GE uplink ports. As part of the CloudEngine 8875 series, it features an advanced hardware architecture that delivers high‑density 200GE access ports and 200GE uplink ports, supporting extensive data center service features with flexible airflow direction (front‑to‑back or back‑to‑front).

The switch is 1U high and comes in a fixed‑configuration form factor. It provides 24 × 200GE QSFP56 downlink ports and 8 × 400GE QSFP‑DD uplink ports. All 200GE ports can automatically adapt to operate at 100 Gbit/s or 40 Gbit/s, and 400GE ports can automatically adjust to 200 Gbit/s, 100 Gbit/s, or 40 Gbit/s. The switch supports port splitting for flexible deployment: a 100GE port can be split into four 25GE SFP28 ports or four 10GE SFP+ ports, and a 400GE QSFP‑DD port can be split into four 100GE QSFP28 ports or two 200GE QSFP56 ports. Split ports support IEEE 1588v2 (PTP).

The CE8875‑24BQ8DQ runs on Huawei’s next‑generation operating system and supports a rich set of data center features including VXLAN routing and bridging, BGP‑EVPN, M‑LAG, PFC, AI ECN, and RoCE v1/v2. It seamlessly integrates with CloudEngine 16800 or 16800‑X data center core switches to build an elastic, virtualized, high‑quality, and fully‑connected 40GE/100GE/200GE data center network. The switch can also function as a core or aggregation switch in campus networks.

Key differentiators include high‑density 200GE access with 400GE uplink capabilities, flexible port rate adaptation and splitting, M‑LAG for cross‑device link aggregation with active‑active load sharing and independent upgrade capability, advanced virtualization with VXLAN and BGP‑EVPN, intelligent lossless network features (PFC, AI ECN), comprehensive Telemetry and iFIT for intelligent O&M, and support for IEEE 1588v2 precision time synchronization.

The chassis is supplied without fan boxes and power modules, which must be ordered separately. It supports 1+1 redundant, hot‑swappable power modules and N+1 redundant, hot‑swappable fan modules.

Product Specifications

Category	Specification
Model	CE8875‑24BQ8DQ
Product Type	Data Center Switch (Fixed Configuration)
Chassis Height	1U
Switching Capacity	16 Tbps
Forwarding Rate	2400 Mpps
System Buffer	64 MB – 72 MB
MAC Address Table	128,000
ARP Entries	128K
IPv6 ND Table Size	128K
Maximum VRFs	4096
Downlink Ports	24 × 200GE QSFP56 (adaptable to 100GE or 40GE)
Uplink Ports	8 × 400GE QSFP‑DD (adaptable to 200GE, 100GE, or 40GE)
Total Port Count	32 ports
Port Splitting	100GE port → 4 × 25GE SFP28 or 4 × 10GE SFP+ (up to 96 × 25GE or 96 × 10GE total); 400GE port → 4 × 100GE QSFP28 or 2 × 200GE QSFP56
Power Supply Type	AC / HVDC / DC (pluggable, hot‑swappable)
Power Module Options	1000W AC & 240V DC; 1200W DC; 600W AC & 240V DC
Rated Voltage Range (AC)	90V AC to 290V AC, 45Hz–65Hz
Rated Voltage Range (HVDC)	190V DC to 290V DC
Rated Voltage Range (DC)	-38.4V DC to -72V DC; +40V DC to +57V DC
Typical Power Consumption	291W (100% load, 12×200G + 4×400G ports with copper cables, room temperature, dual AC power)
Maximum Power Consumption	522W (100% load, 24×200G + 8×400G ports with short‑range optical modules, room temperature, dual AC power)
Power Supply Redundancy	1+1 backup, hot‑swappable
Fan Redundancy	N+1 redundant, hot‑swappable
Dimensions (W × D × H)	442.0 mm × 420.0 mm × 43.6 mm (17.4 in × 16.5 in × 1.72 in)
Weight	9.16 kg
Operating Temperature	0°C to 40°C (0m–1800m altitude)
Storage Temperature	-40°C to +70°C
Operating Humidity	5% to 95% (non‑condensing)
Airflow Direction	Flexible (front‑to‑back or back‑to‑front)
Mounting	Rack‑mountable (1U)
Stacking	Not supported

Supported Features

Feature Category	Supported Capabilities
Virtualization	VXLAN routing and bridging, BGP‑EVPN
Intelligent Lossless Network	PFC (Priority Flow Control), AI ECN (Explicit Congestion Notification), RoCE v1 and RoCE v2
Link Aggregation	M‑LAG (Multichassis Link Aggregation Group) – cross‑device link aggregation, active‑active load sharing, independent node upgrade with zero service interruption
High Availability	Hardware BFD (minimum 3.3ms interval), VRRP, VRRP load sharing, BFD for VRRP/BGP/IS‑IS/OSPF/static routing/VXLAN, LACP, STP/RSTP/VBST/MSTP, SmartLink, DPFR, MoFRR, DPCF
Precision Time Protocol	IEEE 1588v2 (PTP)
QoS	ACL, CAR, Remark, Schedule; PQ, DRR, PQ+DRR queue scheduling; WRED and tail drop congestion avoidance; Traffic shaping
VLAN	Access, Trunk, Hybrid modes; default VLAN
Multicast	IGMP Snooping, IGMP Proxy, IGMP, PIM‑SM, MSDP multicast routing protocols; IPv6 multicast; Multicast traffic suppression; Multicast NAT
Security	MACsec, Micro‑segmentation security isolation (IPv4 and IPv6), Command‑line privilege level protection, DoS/ARP/ICMP attack prevention, Port isolation, Port security, Sticky MAC, IP‑MAC‑port‑VLAN binding, AAA, LDAP, RADIUS, HWTACACS authentication
IPv6	IPv6 ND, PMTU discovery, IPv6 TCP/Ping/Tracert/Socket/UDP/RawIP; IPv6 VXLAN over IPv4/IPv6; RIPng, OSPFv3, ISISv6, BGP4+
IPv4 Routing	RIP, OSPF, ISIS, BGP dynamic routing protocols
O&M & Telemetry	Telemetry, NetStream, sFlow, SPAN/RSPAN/ERSPAN enhanced, iFIT (In‑situ Flow Information Telemetry), Packet event root‑cause analysis
Configuration & Maintenance	Console, Telnet, SSH terminal services; SNMPv1/v2c/v3; RMON; FTP/TFTP file transfer; Zero‑Touch Provisioning (ZTP); Hot patching; Configuration rollback
SDN Integration	OpenFlow support, integration with iMaster NCE‑Fabric
