Huawei S2720-52TP-EI-AC Switch – Product Documentation

Name: Huawei S2720-52TP-EI-AC Switch - SunSpike
SKU: S2720-52TP-EI-AC

Product Overview

The Huawei S2720-52TP-EI-AC is a next-generation energy-saving 100M Ethernet intelligent managed switch belonging to the Huawei S2700 series Ethernet switches. Leveraging cutting-edge switching technologies and the Huawei Versatile Routing Platform (VRP) software, this switch is designed to meet the demands of multi-service provisioning and access on Ethernet networks.

The S2720-52TP-EI-AC is a Layer 3 enterprise-grade switch that provides 52 fixed ports, including 32 × 10/100BASE-TX ports, 16 × 10/100/1000BASE-T ports, and 4 × Gigabit SFP uplink ports. It delivers a switching capacity of 336 Gbps and a forwarding performance of 34.8 Mpps.

The switch is easy to install and maintain, supporting flexible VLAN deployment, comprehensive security and QoS policies, and energy-saving technologies that help enterprise customers build next-generation IT networks. It supports a wide range of advanced features including static routing, RIP, OSPF, IPv6, multicast snooping, iStack virtual stacking, and Super Virtual Fabric (SVF) client functionality.

Technical Specifications

Item	Specification
Product Model	S2720-52TP-EI-AC
Product Type	Enterprise-grade switch
Application Layer	Layer 3
Switching Capacity	336 Gbps
Forwarding Performance	34.8 Mpps
MAC Address Table	16K
Fixed Ports	32 × Ethernet 10/100BASE-TX ports, 16 × Ethernet 10/100/1000BASE-T ports, 4 × GE SFP ports
Extended Slot	N/A
Console Port	1 × Console port
PNP Button	1 × PNP button (long press ≥6s: restore factory settings and reset; short press: reset switch)
VLAN	4K active VLANs; Guest VLAN and voice VLAN; GVRP; MUX VLAN; VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and interfaces; 1:1 and N:1 VLAN mapping
Ethernet Loop Protection	RRPP ring topology and RRPP multi-instance; Smart Link tree topology and Smart Link multi-instance (millisecond-level protection switchover); SEP; ERPS (G.8032); STP (IEEE 802.1d), RSTP (IEEE 802.1w), and MSTP (IEEE 802.1s)
Reliability	EFM OAM (802.3ah); CFM OAM (802.1ag); ITU-Y.1731; DLDP; LACP
IP Routing	Static route, RIP, RIPng, OSPF
IPv6	Neighbor Discovery (ND); Path MTU (PMTU); IPv6 ping, IPv6 tracert, and IPv6 Telnet
Multicast	IGMPv1/v2/v3 snooping; Controllable multicast; Interface-based multicast traffic statistics; MLDv1/v2 snooping
QoS/ACL	Rate limiting by interface; Eight queues on each interface; WRR, DRR, SP, WRR+SP, and DRR+SP queue scheduling algorithms; Re-marking of 802.1p priority and DSCP priority; Rate limiting in each queue and traffic shaping on interfaces
Security	Port isolation, port security, and sticky MAC; MFF; Blackhole MAC address entries; Limit on number of learned MAC addresses; IEEE 802.1x authentication and limit on number of users on an interface; AAA authentication, RADIUS authentication, HWTACACS authentication, and NAC; SSH V2.0; HTTPS; CPU defense; Blacklist and whitelist; DHCP relay, DHCP server, DHCP snooping; DHCPv6 relay, DHCPv6 server, DHCPv6 snooping
Super Virtual Fabric (SVF)	Works as an SVF client that is plug-and-play with zero configuration; Automatically loads system software package and patches; One-click and automatic delivery of service configurations; Supports independent running client
Management & Maintenance	iStack (intelligent stacking); Virtual Cable Test (VCT); Remote configuration and maintenance using Telnet; SNMPv1/v2c/v3; RMON; eSight network management system; WEB network management; HTTPS; LLDP/LLDP-MED; System logs and hierarchical alarms; 802.3az Energy-Efficient Ethernet (EEE)
Power Supply	Fixed AC power; Rated voltage range: 100–240V AC, 50–60Hz; Maximum voltage range: 90–264V AC, 47–63Hz
Maximum Power Consumption	40.3W
Dimensions (W × D × H)	442 × 220 × 43.6 mm (17.4 × 8.7 × 1.7 in)
Operating Temperature	0°C to 45°C
Operating Humidity	5% to 95% (non-condensing)
