Huawei CloudEngine S12700E-8 Switch – Product Information Sheet

Name: Huawei CloudEngine S12700E-8 Switch - SunSpike
SKU: S12700E-8

Product Overview

The Huawei CloudEngine S12700E-8 is a flagship core switch within Huawei’s CloudCampus portfolio, purpose-built for next-generation high-quality campus networks in the Wi-Fi 6 era. Designed for large-scale enterprise deployments across government, finance, energy, and other industries, the S12700E-8 delivers industry-leading data switching capacity and massive terminal access capabilities.

Built on Huawei’s high-performance full-programmable Solar chipsets, the S12700E-8 implements data plane processing through ASICs and delivers 4.8 Tbps of single-slot bandwidth, which can scale to 7.2 Tbps simply by upgrading Switch Fabric Units (SFUs) in the future. The switch employs advanced cell switching technology to achieve true non-blocking switching with zero packet loss.

The S12700E-8 features a control and forwarding separation architecture with 8 service slots, 4 independent SFU slots, 2 MPU slots, and 6 power module slots. It supports a wide range of line cards including 100GE, 40GE, 25GE, 10GE, and GE interfaces, offering up to 192 x 100GE, 192 x 40GE, 320 x 25GE, or 384 x 10GE ports per chassis.

The switch integrates large-capacity WLAN AC capabilities, enabling a single unit to manage up to 10,240 wireless APs and over 50,000 wireless users. It supports wired and wireless convergence with unified user management and policy enforcement. Additional features include VxLAN L2/L3 gateway support with BGP-EVPN, Super Virtual Fabric (SVF) for managing up to 10K client nodes as a single device, iPCA for real-time packet loss detection, and full programmability for service upgrades without hardware replacement.

The S12700E-8 offers extensive interoperability with third-party devices through VBST (compatible with PVST/PVST+/RPVST), LNP (similar to DTP), and VCMP (similar to VTP).

Technical Specifications

Category	Specification
Product Model	CloudEngine S12700E-8
Product Type	Flagship modular core switch for campus networks
Switching Capacity	38.4 Tbit/s / 57.6 Tbit/s (current/ready)
Forwarding Performance	28,800 Mpps
Service Card Slots	8
SFU (Switch Fabric Unit) Slots	4
MPU (Main Processing Unit) Slots	2
Power Module Slots	6
Fan Slots	4
Single-Slot Bandwidth	4.8 Tbps (scalable to 7.2 Tbps via SFU upgrade)
Maximum Port Density	• 192 x 100GE ports • 192 x 40GE ports • 320 x 25GE ports • 384 x 10GE ports
MAC Address Table	512K
Dimensions (H x W x D)	663.9 x 442 x 517.4 mm
Maximum Power Consumption	6950W
Power Supply	AC or DC power
Wireless Services	Manages up to 10K APs; AP access control, AP domain management, AP configuration template management; radio channel management; WLAN basic services, QoS, security, and user management; CAPWAP, tag/terminal location, and spectrum analysis
iPCA (Packet Loss Measurement)	Real-time statistics on lost packet count and packet loss ratio at network and device levels
SVF (Super Virtual Fabric)	Up to 10K clients (access switches and APs) virtualized as a single device; supports two-layer client architecture; supports third-party devices between SVF parent and clients
VXLAN	VXLAN L2 and L3 gateways; centralized and distributed gateways; BGP-EVPN; configuration through NETCONF protocol
Interoperability	VBST (compatible with PVST, PVST+, RPVST); LNP (similar to DTP); VCMP (similar to VTP)
QoS Support	ACL rule count: 6K; supports combined flow classification based on Layer 2 protocol headers, Layer 3 protocols, Layer 4 protocols, 802.1p priority, etc.; supports ACL, CAR, Remark, Schedule actions; supports PQ scheduling
VLAN Features	Supports LNP link type auto-negotiation; supports default VLAN; supports VLAN switching; supports QinQ
Management	Supports NETCONF protocol for configuration
