Huawei CloudEngine CE16804-AH – Data Center Switch

Name: Huawei CloudEngine CE16804-AH – Data Center Switch - SunSpike
SKU: CE16804-AH

Product Overview

The Huawei CloudEngine CE16804-AH is a high-performance modular chassis switch belonging to the CloudEngine 16800 Series, designed for data center core, cloud computing infrastructure, and large-scale enterprise backbone networks. As part of Huawei’s next-generation modular switching platform, it features an innovative backplane-free Clos architecture with cell switching and Virtual Output Queue (VoQ) technology, delivering high throughput, low latency, and exceptional scalability.

The switch chassis is 9.8U high and features a 4-slot architecture with service slots supporting flexible combinations of line processing units (LPUs). It includes 2 main processing unit (MPU) slots for 1:1 redundancy and up to 9 switching fabric unit (SFU) slots (6 factory-configured, scalable to 9 for future expansion). The CE16804-AH supports AC and HVDC dual power input configurations with up to 6 power modules and a 5+1 or N+M redundant power architecture. It adopts a strict front-to-back airflow design optimized for hot aisle/cold aisle data center layouts.

The CE16804-AH supports high-speed Ethernet evolution including 100GE, 200GE, and 400GE, enabling flexible data center expansion and seamless network scalability. It is widely deployed in spine-leaf architectures, hyperscale cloud platforms, high-performance computing environments, and telecom carrier-grade networks. The system integrates intelligent traffic management, carrier-grade redundancy design, and modular expansion capabilities, making it a critical foundation for next-generation network infrastructure.

Key differentiators of the CE16804-AH include its high-density modular architecture with up to 903 Tbps switching capacity, the innovative iLossless intelligent algorithm for zero packet loss and end-to-end microsecond-level latency, comprehensive VXLAN routing and bridging with BGP-EVPN support, M-LAG for cross-device link aggregation with independent upgrade capability, millisecond-level Telemetry data collection for intelligent O&M, and support for RoCE v1/v2 and IEEE 1588v2 for lossless, time-synchronized networks.

The chassis is supplied without power modules and fan modules, which must be ordered separately.

Product Specifications

Category	Specification
Model	CE16804-AH
Part Number	02352RCU
Product Type	Data Center Switch (Modular Chassis)
Chassis Height	9.8U
Service Slots (LPU)	4
MPU Slots	2 (1:1 redundancy)
SFU Slots	6 (scalable to 9 for future expansion)
Switching Capacity	903 Tbps / 2709 Tbps
Packet Forwarding Rate	230,400 Mpps
Switching Fabric Architecture	Clos architecture, cell switching, VoQ (Virtual Output Queue)
Airflow Design	Strict front-to-back airflow
Redundant MPUs	1:1
Number of Power Modules	6
Power Supply Redundancy	5+1 or N+M redundant architecture
Power Supply Type	AC / HVDC (pluggable, hot-swappable)
Rated Voltage (AC)	220V, 50/60Hz
Rated Voltage (HVDC)	240V / 380V
Maximum Output Power (AC, 5+1 mode)	3000W × 5 = 15000W
Maximum Output Power (HVDC, 5+1 mode)	2200W × 5 = 11000W
Maximum Input Current	16A @ 200V
Weight	110 kg
Dimensions (H × W × D)	9.8U × 19-inch rack-mountable
Mounting	Rack-mountable (cabinet installation)
First Supported Version	V200R005C20 (V200) / V300R020C00 (V300)

Key Features Supported

Feature Category	Supported Capabilities
Virtualization	VXLAN routing and bridging, BGP-EVPN, QinQ access VXLAN
Intelligent Lossless Network	iLossless intelligent algorithm (zero packet loss, E2E μs-level latency), RoCE v1 and RoCE v2, PFC, AI ECN
Link Aggregation	M-LAG (Multichassis Link Aggregation Group) – cross-device link aggregation, active-active load sharing
High Availability	LACP, Hardware BFD (minimum 3.3ms interval), VRRP, M-LAG, DPFR, MoFRR, DPCF
Precision Time Protocol	IEEE 1588v2
QoS	VLAN, STP, LACP; Static route, IPv4/IPv6 dynamic routing protocols; IP packet fragmentation and reassembly
Security	Micro-segmentation security isolation (IPv4 and IPv6), MACsec
O&M & Telemetry	Telemetry (millisecond-level data collection), NetStream, sFlow, SPAN/RSPAN/ERSPAN enhanced, iPCA, iFIT (In-situ Flow Information Telemetry), Packet Event root-cause analysis
Programmability & Automation	Standard NETCONF northbound interface, Ansible-based automatic configuration, open-source module release
Configuration & Maintenance	Console, Telnet, SSH terminal services; SNMP; FTP/TFTP file transfer; Hot patching; Configuration rollback
