Huawei OceanStor 2100 V3 — Product Overview & Specifications
Product Overview
The Huawei OceanStor 2100 V3 is a new-generation entry-level enterprise storage system designed for small and medium-sized businesses. It delivers economical efficiency and sophisticated features in a compact form factor, making it suitable for a wide range of applications including database OLTP/OLAP, Exchange, server virtualization, and video surveillance .
The system supports 16Gbps FC, 10Gbps FCoE, and 1/10Gbps Ethernet host interfaces, leveraging a next-generation PCIe 3.0 bus and 12Gbps SAS 3.0 high-speed disk interface for performance and specifications that lead its class . It employs a flash-oriented operating system that harnesses the combined advantages of flash storage and traditional hard disk storage .
The OceanStor 2100 V3 offers a rich set of Hyper-series data protection software to meet local, remote, and multi-site data protection requirements, ensuring business continuity and data availability . Its SmartConfig ease-of-use software dramatically simplifies the storage configuration process, requiring only three steps and minutes to complete resource provisioning — addressing the skill bottlenecks of IT operations personnel .
With its compact chassis design, low noise output, and reduced power consumption, the system minimizes environmental requirements. It also supports intelligent data tiering (SmartTier), which identifies hot data and prioritizes its performance, enabling the storage system to adapt to growing business demands over its lifecycle .
Specifications
| Parameter | Details |
|---|---|
| Product Type | Hybrid Flash Storage / Entry-Level Enterprise Storage |
| Controller Configuration | Dual Controller (max. 2 controllers) |
| System Cache | 16GB (dual controller) |
| Storage Protocols | FC, FCoE, iSCSI |
| Front-End Port Types | 1/10Gbps Ethernet, 10Gbps FCoE, 8/16Gbps FC |
| Back-End Port Types | SAS 3.0 (single port: 4 × 12Gbps) |
| Max. Front-End Host Ports (per Controller) | 12 |
| Max. Hot-Swappable I/O Modules (per Controller) | 1 |
| Drive Bays | 12 × 3.5″ (control enclosure); up to 300 total drive slots |
| Drive Types | SSD, SAS, NL-SAS |
| RAID Levels | RAID 0, 1, 3, 5, 6, 10, 50 |
| Block-Level Virtualization | Yes (data balanced distribution, rapid fault recovery) |
| Power Supply | AC: 100–240V |
| Operating Temperature | 5°C–40°C at altitude –60m to 1,800m; above 1,800m, temperature decreases 1°C per 220m increase |
| Operating Humidity | 5% RH – 90% RH |
| Dimensions (Control Enclosure) | 2U: 86.1 × 447 × 488 mm |
| Dimensions (Drive Enclosure) | 2U: 86.1 × 447 × 490 mm; 4U: 175 × 447 × 490 mm |
| Weight (Control Enclosure) | < 24 kg |
| Weight (Drive Enclosure) | 2U: < 20 kg; 4U: ≤ 44 kg |
Software Features
| Category | Features |
|---|---|
| Data Protection | HyperSnap (snapshot), HyperCopy (LUN copy), HyperClone (clone), HyperMirror (volume mirror), HyperReplication (remote replication) |
| Resource Efficiency | SmartTier (intelligent data tiering), SmartCache (SSD cache), SmartThin (thin provisioning), SmartMotion (data migration), SmartMigration (LUN migration), SmartErase (data destruction) |
| Storage Management | UltraPath (multipath management), DeviceManager (single-device management), eSight (centralized O&M management), BCManager (disaster recovery management), SmartConfig (configuration tool) |
| Virtualization | Heterogeneous virtualization, block-level virtualization, compute virtualization |
| QoS | SmartQoS (intelligent quality of service control) |
