Huawei CloudEngine S6730S-S24X6Q-A

Name: Huawei CloudEngine S6730S-S24X6Q-A - Refurbished & Tested - SunSpike
Brand: HUAWEI
SKU: S6730S-S24X6Q-A

Product Overview

The Huawei CloudEngine S6730S-S24X6Q-A is a next-generation, fixed-configuration 10GE switch designed for high-density campus and data center networks. It delivers high-speed access for Wi-Fi 6 access points (APs) and 10 Gbit/s server connectivity, making it an ideal solution for the core or aggregation layers of a network. This switch offers 24 x 10GE SFP+ downlink ports and 6 x 40GE QSFP+ uplink ports, providing a robust switching capacity of up to 2.4 Tbit/s.

The S6730S-S24X6Q-A is engineered for intelligence and simplified operations. It supports SVF (Super Virtual Fabric) , which virtualizes core/aggregation switches, access switches, and wireless APs into a single logical device for streamlined management. It also features built-in Telemetry for real-time data collection, and when paired with the CampusInsight network analyzer, it enables rapid fault detection and precise identification of network issues affecting user experience. Furthermore, its iPCA (Packet Conservation Algorithm for Internet) provides real-time, hop-by-hop packet loss statistics for precise network quality monitoring. The switch also supports iStack, which combines multiple switches into a single logical stack to enhance reliability and simplify management.

Technical Specifications

Category	Specification
Model	CloudEngine S6730S-S24X6Q-A
Forwarding Performance	480 Mpps
Switching Capacity	960 Gbps / 2.4 Tbps
Fixed Ports	24 x 10 GE SFP+ and 6 x 40 GE QSFP+
Dimensions (W x D x H)	442 mm x 420 mm x 43.6 mm (1U)
Chassis Height	1U
MAC Address Table	64K
VLAN Features	Supports 4K VLANs, Guest VLAN, Voice VLAN, MUX VLAN, VLAN Mapping
Input Voltage (AC)	Rated: 100-240V AC, 50/60Hz; Max: 90-290V AC, 45-65Hz
Input Voltage (DC)	-48V to -60V
Maximum Power Consumption	225W (220V input), 249W (90V input)
Minimum Power Consumption	88W
Operating Temperature	-5°C to 45°C (at 0-1800m altitude)
Storage Temperature	-40°C to 70°C
Operating Altitude	Up to 5000m
Acoustic Noise (Normal Temp.)	52 dB(A)
Fan	4 hot-swappable fans with intelligent speed control
Cooling	Air cooling, front-to-back airflow
Relative Humidity	5% to 95% (non-condensing)
Surge Protection (AC)	Differential mode: ±6kV; Common mode: ±6kV
Surge Protection (DC)	Differential mode: ±2kV; Common mode: ±4kV
Stacking	Supports iStack
Layer 3 Routing	Static, RIP, OSPF, IS-IS, BGP (IPv4 and IPv6)
Management & O&M	Cloud management, SNMP, RMON, NetStream, Telemetry, iPCA
Reliability Features	LACP, E-Trunk, BFD, Ethernet OAM (802.3ah, 802.1ag), DLDP, LLDP
Security Features	802.1X, AAA, SSH, HTTPS, IPSec, DOS/ARP attack prevention
Super Virtual Fabric (SVF)	Supported as a Parent node
