Huawei CloudEngine S2730S-S48FT4S-A
S2730S-S48FT4S-A
Enterprise stock · tested · export documentation available
Huawei CloudEngine S2730S-S48FT4S-A – Product Information
Product Overview
The Huawei CloudEngine S2730S-S48FT4S-A is a next-generation green energy-efficient intelligent 100M/1000M access switch from Huawei’s CloudEngine S2730S-S series. Built on next-generation high-performance hardware and Huawei’s unified VRP (Versatile Routing Platform) software platform, this switch delivers flexible Ethernet networking and diverse security control capabilities. It supports multiple Layer 3 routing protocols, offering higher performance and richer service processing capabilities.
This model features a combination of 24 10/100BASE-TX ports, 24 10/100/1000BASE-T ports, and 4 Gigabit SFP ports, making it suitable for a wide range of deployment scenarios including enterprise campus access and 100M/1000M-to-desktop applications. The switch supports intelligent stacking through the iStack feature, enabling up to 9 units to be stacked together for simplified device management. It incorporates rich energy-saving designs including fan speed regulation, port sleep, and automatic power adjustment technologies.
Specifications
| Category | Specification |
|---|---|
| Model | S2730S-S48FT4S-A |
| Part Number | 98011337 |
| Product Type | Gigabit Ethernet Switch, Managed Switch |
| Application Layer | Layer 3 |
| Switching Capacity | 432 Gbps |
| Packet Forwarding Rate | 45.6 Mpps |
| Switching Mode | Store-and-Forward |
| Port Structure | Non-modular |
| Total Ports | 52 |
| Fixed Ports | 24 × 10/100BASE-TX Ethernet ports, 24 × 10/100/1000BASE-T Ethernet ports, 4 × Gigabit SFP ports |
| Console Port | 1 × RJ45 console port |
| Stacking Support | Stackable (iStack, up to 9 units) |
| MAC Address Table | 16K MAC addresses; supports automatic learning and aging; supports static, dynamic, and blackhole MAC entries; supports MAC address learning limit per interface |
| VLAN Features | Supports 4K VLANs; VLAN based on MAC/protocol/IP subnet/policy/port; port-based QinQ; Guest VLAN, Voice VLAN; GVRP; MUX VLAN; 1:1 and N:1 VLAN Mapping |
| IP Routing | Static routes; RIP, RIPng, OSPF |
| Multicast Management | PIM DM, PIM SM, PIM SSM; MLD v1/v2 and MLD v1/v2 Snooping; IGMP v1/v2/v3 and IGMP v1/v2/v3 Snooping; VLAN multicast forwarding and multicast VLAN replication; multicast load balancing across bundled ports; controllable multicast; port-based multicast traffic statistics |
| QoS | Rate limiting on ingress and egress per port; packet redirection; port-based traffic policing with dual-rate three-color CAR; 8 queues per port; WRR, DRR, SP, WRR+SP, DRR+SP queue scheduling; 802.1p and DSCP priority remarking; L2–L4 packet filtering (source/destination MAC, source/destination IP, TCP/UDP ports, protocol, VLAN); queue-based rate limiting and port shaping |
| Network Management | Intelligent stacking iStack; Netconf/Yang-based cloud management; Virtual Cable Test; Telnet; SNMPv1/v2c/v3; RMON; eSight management system; WEB-based management; HTTPS; LLDP/LLDP-MED; system logs;分级 alarms; 802.3az Energy Efficient Ethernet |
| Security Management | User分级 management and password protection; DoS, ARP, and ICMP attack prevention; IP, MAC, port, VLAN binding; port isolation, port security, Sticky MAC; MFF; blackhole MAC; MAC address learning limit; IEEE 802.1X authentication with per-port user limit; AAA authentication (RADIUS, HWTACACS, NAC); SSH V2.0; HTTPS; CPU protection |
| Interoperability | VBST (interoperable with PVST/PVST+/RPVST); LNP (similar to DTP); VCMP (similar to VTP) |
| Power Supply | Built-in AC power supply, 100–240V AC, 50/60Hz |
| Maximum Power Consumption | 50.4 W |
| Typical Power Consumption | 43.3 W |
| Maximum Heat Dissipation | 171.97 BTU/hour |
| Typical Heat Dissipation | 147.74 BTU/hour |
| Dimensions (W × D × H) | 442 × 220 × 43.6 mm |
| Weight | 2.76 kg |
| Operating Temperature | -5°C to 50°C (long-term), -5°C to 55°C (short-term) |
| Storage Temperature | -40°C to 70°C |
| Operating Humidity | 5% to 95% |
| Lightning Protection (Service Ports) | Common mode: ±10 kV |
| Lightning Protection (Power Port) | Differential mode: ±6 kV, Common mode: ±6 kV |
| Cooling Method | Fanless, natural heat dissipation |
| First Supported Version | V200R020C10 |
