Huawei CloudEngine S2309TP-PWR-EI-AC – Product Documentation

Name: Huawei CloudEngine S2309TP-PWR-EI-AC - Refurbished & Tested - SunSpike
Brand: HUAWEI
SKU: S2309TP-PWR-EI-AC

Product Overview

The Huawei CloudEngine S2309TP-PWR-EI-AC is a managed Layer 2 access switch from the S2300 series, designed for enterprise edge deployments requiring integrated Power over Ethernet capabilities. This compact 1U device combines eight Fast Ethernet PoE access ports with a Gigabit Combo uplink port, allowing organizations to power IP phones, wireless access points, surveillance cameras, and other connected devices directly over Ethernet cables while maintaining high-speed uplink connectivity to aggregation or core networks .

As an Enhanced Edition (EI) model, this switch delivers richer VLAN, QoS, multicast, and security capabilities compared to standard SI versions. It supports advanced features including QinQ VLAN encapsulation, 1:1 and N:1 VLAN switching, flexible VLAN assignment based on port or MAC address, and comprehensive traffic classification and prioritization . The switch runs on Huawei’s VRP software platform, providing robust ACL control with VLAN-based rule application, enterprise-grade authentication mechanisms (802.1X, RADIUS, HWTACACS+), and multiple management interfaces including CLI, Telnet, SNMP, and Web management .

The device features Huawei’s patented built-in surge protection technology, with each port offering 6 KV surge protection capability (extendable to 15 KV with additional protection devices) . It supports intelligent stacking (iStack) for virtual switch deployment, automatic configuration capabilities, and energy-efficient design with port sleep modes, making it suitable for branch offices, retail locations, educational institutions, and enterprise access networks .

Technical Specifications

Category	Specification
Fixed Ports	8 × 10/100Base-TX PoE ports; 1 × Gigabit Combo port (10/100/1000Base-T or 100/1000Base-X SFP)
PoE Support	IEEE 802.3af and IEEE 802.3at; up to 30 W per port; total PoE power budget 123.2 W (built-in 250 W AC power supply)
Processor	200 MHz dominant frequency
Memory	DDR: 64 MB; Flash: 16 MB
Switching Capacity	3.6 Gbit/s
Forwarding Performance	2.7 Mpps
Backplane Switching Capacity	32 Gbit/s
MAC Address Table	8K entries; supports manual add/delete, aging time configuration, learning disable per port/aggregation group, learning limit, blackhole MAC addresses
VLAN Features	4096 VLANs; port-based VLAN; MAC-based VLAN; basic QinQ; 1:1 VLAN switching; N:1 VLAN switching
QoS	Port rate limit and traffic rate limit; 4 priority queues per port; 802.1p mapping; SP, WRR, SP+WRR scheduling; traffic classification by source/destination MAC/IP, Layer-4 port, protocol type, VLAN ID, Ethernet frame protocol type, CoS
IPv6 Features	IPv6 host functions; static routes; IPv6 ACL; MLD v1/v2 snooping
Multicast	IGMP v1/v2/v3 snooping; multicast load sharing among bundled ports; port-based multicast rate limit and traffic statistics
Port Mirroring	1:1 or N:1 port mirroring; RSPAN; traffic-based mirroring; observing port packet forwarding
Security	802.1X authentication with per-port user limit; dynamic ARP detection; IP Source Guard; AAA/RADIUS/HWTACACS+/NAC authentication; IP-MAC-port-VLAN binding; port isolation; port security; sticky MAC; packet filtering; MAC address filtering; multicast/broadcast/unknown-unicast suppression; MAC address learning limit; CPU protection
Surge Protection	6 KV per port (15 KV with additional surge protection device)
Management	iStack (intelligent stacking); automatic configuration; CLI; Telnet; SNMP v1/v2/v3; RMON; HGMP v2; SSH v2; Web management; GVRP
Dimensions (W × D × H)	320 mm × 220 mm × 43.6 mm (1U)
Weight	< 2.5 kg
Power Supply	AC: rated voltage 100 V to 240 V, 50/60 Hz; maximum voltage 90 V to 264 V
Maximum Power Consumption	< 154 W (including PoE output)
Operating Environment	Long-term temperature: 0°C to 50°C; short-term: –5°C to 55°C; humidity: 10% to 90% (non-condensing)
Standards Compliance	IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3x, 802.1Q
