Name: ThinkStation P920 Workstation - SunSpike
SKU: LENOVOP920

Lenovo ThinkStation P920 Technical Overview

Feature	Specification
Processor Support	Dual-socket Intel Xeon Scalable Processors (1st Gen “Skylake” & 2nd Gen “Cascade Lake”)
Max Cores / Threads	Up to 2x 28 cores / 56 threads (e.g., Intel Xeon Platinum 8280)
Memory Architecture	6-channel memory architecture per processor
DIMM Slots	16x DDR4 DIMM slots (8 slots per CPU)
Max Memory Capacity	Up to 1TB DDR4-2933MHz ECC RDIMM / LRDIMM (2TB with Optane DC Persistent Memory)

Feature	Specification
Graphics (GPU) Support	Up to 3x NVIDIA Quadro RTX 8000 / RTX 6000 or NVIDIA GV100 (Dual 1400W PSU configuration)
Onboard M.2 NVMe	2x M.2 PCIe NVMe SSD slots onboard (supports RAID 0/1)
Internal Drive Bays	Up to 4x 3.5″ HDD bays (or 8x 2.5″ SATA/SAS/SSD via flex trays)
PCIe RAID Expansion	Supports ThinkStation M.2 PCIe Adapter / Quad M.2 PCIe Adapter
Storage RAID Support	Intel RSTe (SATA RAID 0/1/5/10), Intel VROC (NVMe RAID 0/1/5/10 with HW key)

PCIe Expansion Slots:
- 5x PCIe 3.0 x16 slots
- 3x PCIe 3.0 x4 slots
Power Supply Options:
- 1400W Platinum (92% efficiency, auto-sensing)
- 1000W Platinum (92% efficiency, auto-sensing)

Front Ports:
- 4x USB 3.1 Gen 1 (Type-A)
- 1x 3.5mm Headphone / Microphone combo jack
- 1x SD Card Reader (Optional 15-in-1 card reader)
- 1x Thunderbolt 3 (Optional via Flex Module)
Rear Ports:
- 4x USB 3.1 Gen 1 (Type-A)
- 2x USB 2.0 (Type-A)
- 2x RJ-45 Gigabit Ethernet ports (Intel I219-LM & Intel I210-AT)
- 1x Serial Port (Optional)
- 1x Audio Line-in, 1x Audio Line-out, 1x Microphone-in
- PS/2 ports (Optional)
