Product Overview

The Lenovo ThinkSystem SR630 V2 is a 1U, two-socket rack server designed to deliver mainstream performance and density for hybrid data center workloads. Built on the 3rd generation Intel Xeon Scalable processor family (formerly codenamed “Ice Lake”) and supporting Intel Optane Persistent Memory 200 Series, the SR630 V2 addresses workloads ranging from cloud and virtualization to analytics, high-performance computing, and gaming.

The system supports up to two processors with up to 40 cores each, delivering a maximum of 80 cores per server. With 32 DDR4 memory slots and support for up to 8TB of system memory using 256GB 3DS RDIMMs, the SR630 V2 provides substantial memory capacity for in-memory databases and dense virtualization deployments.

Storage flexibility is a defining characteristic of this platform. Lenovo AnyBay backplane technology allows SAS, SATA, U.2/U.3 NVMe, or EDSFF drives to be configured within the same drive bay, giving organizations the freedom to mix high-capacity SAS drives with high-performance NVMe SSDs in a single chassis. The server supports up to 12x 2.5-inch NVMe drives with direct PCIe lane connectivity (no oversubscription), as well as configurations using 3.5-inch drives or 16x EDSFF E1.S form factor drives.

The SR630 V2 includes Lenovo XClarity Controller for comprehensive systems management with Redfish-compliant REST APIs, and Lenovo ThinkShield for end-to-end security from development through the full device lifecycle. The platform supports up to three single-width 75W GPUs, making it suitable for workloads requiring acceleration within a dense 1U form factor.

Product Resources List

• Quick Start Guide — Product overview and guidance for support

• Setup Guide — Hardware installation and initial setup procedures

• Maintenance Manual — Hardware replacement and troubleshooting instructions

• Messages and Codes Reference — XClarity Controller, LXPM, and UEFI event codes

• UEFI Manual — UEFI firmware settings documentation

• Rack Installation Guide — Server installation in a rack cabinet

• CMA Installation Guide — Cable management arm installation on rails

• Lenovo Press Product Guide — Detailed technical product guide and datasheet

• Operating System Interoperability Guide — Complete list of supported and certified operating systems

• Lenovo ServerProven — Compatibility lookup for processors, memory, drives, and adapters
