Huawei FusionServer 2488H V6 – Product Documentation
Product Overview
The FusionServer 2488H V6 is a high-performance 2U, 4-socket rack server engineered for compute-intensive enterprise workloads including cloud computing, virtualization, high-performance computing (HPC), database management, and SAP HANA deployments.
In virtualization scenarios, a single 2488H V6 delivers lower operational expenditure (OPEX) compared to two 2U, 2-socket rack servers, making it a cost-efficient consolidation platform. The system houses four 3rd Generation Intel® Xeon® Scalable processors within a compact 2U form factor, supporting up to 48 DDR4 DIMMs, 11 PCIe expansion slots, and flexible local storage configurations with up to 25 x 2.5″ drives.
The server incorporates patented technologies including Dynamic Energy Management Technology (DEMT) for intelligent power optimization and Fault Diagnosis & Management (FDM) for enhanced system reliability. It can be optionally configured with FusionDirector software for full lifecycle management, enabling automated operations and intelligent O&M capabilities.
Technical Specifications
| Category | Parameter | Description |
|---|---|---|
| Model | Product Name | FusionServer 2488H V6 |
| Form Factor | Chassis Type | 2U rack server |
| Dimensions | Height × Width × Depth | 86.1 mm × 447 mm × 790 mm (3.39 in. × 17.60 in. × 31.10 in.) |
| Weight | Approximate | 32 kg |
| Processors | CPU Type | 2 or 4 × 3rd Gen Intel® Xeon® Scalable processors (5300/6300/8300 series) |
| TDP | Up to 250 W per processor | |
| Max Cores | Up to 112 cores per system | |
| Memory | Type | DDR4 DIMM |
| Slots | 48 DIMM slots | |
| Speed | Up to 3200 MT/s | |
| Optane™ PMem | Up to 24 × Intel® Optane™ Persistent Memory 200 series modules at 2666 MT/s | |
| Max Capacity | Up to 18 TB with Optane™ PMem | |
| Local Storage | Drive Bays (Front) | Hot-pluggable configurations: • 8 × 2.5″ SAS/SATA/NVMe drives • 24 × 2.5″ SAS/SATA drives • 25 × 2.5″ SAS/SATA drives • 4 × 2.5″ SAS/SATA + 8 × NVMe SSDs • 4 × 2.5″ SAS/SATA + 16 × NVMe SSDs |
| Flash Storage | 2 × M.2 SSDs | |
| RAID Support | RAID Levels | RAID 0, 1, 5, 50, 6, 60 |
| Features | Optional supercapacitor for cache power-off protection; RAID-level migration, drive roaming, self-diagnosis, web-based remote configuration | |
| PCIe Expansion | Slots | Up to 11 × PCIe 3.0 slots (including one dedicated slot for OCP 3.0 NIC) |
| GPU Accelerators | Support | 2 × dual-slot FHFL or 4 × single-slot HHHL GPU accelerator cards |
| Max Compute | Up to 560 TFLOPS per node | |
| Cooling | Fan Modules | 6 × hot-swappable counter-rotating fan modules, N+1 redundancy |
| Power Supplies | Configuration | 2 × hot-swappable PSUs, 1+1 redundancy |
| 3000 W AC Titanium | 2500 W (200–220 V AC), 2900 W (220–230 V AC), 3000 W (230–240 V AC) | |
| 2000 W AC Platinum | 1800 W (200–220 V AC / 192–200 V DC), 2000 W (220–240 V AC / 200–288 V DC) | |
| 900 W AC Platinum/Titanium | 100–240 V AC / 192–288 V DC | |
| 1500 W HVDC | 260–400 V DC | |
| 1200 W DC | -38.4 V DC to -72 V DC | |
| Management | BMC | Integrated dedicated management GbE port; supports Redfish, SNMP, IPMI 2.0 standards |
| Remote Management | HTML5/VNC KVM interface; CD-free deployment; Agentless management | |
| Optional Software | FusionDirector for full lifecycle intelligence, automated O&M, OS batch deployment, firmware auto-upgrade | |
| Operating Environment | Temperature | 5°C to 45°C (41°F to 113°F), compliant with ASHRAE A2 standards |
| Security | Features | Power-on password, administrator password, TCM/TPM 2.0, security panel, tamper detection |
| Certifications | Compliance | CE, UL, FCC, CCC, RoHS |
| Operating Systems | Support | Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, CentOS, Citrix XenServer, VMware ESXi |
