Huawei FusionServer Pro 2288X V5 – Product Documentation & Specifications
Product Overview
The Huawei FusionServer Pro 2288X V5 is a 2U rack-mount enterprise server designed for data centers requiring high performance, scalability, and energy efficiency. It supports up to two 1st or 2nd generation Intel® Xeon® Scalable processors, delivering powerful computing capabilities for a wide range of workloads including virtualization, cloud computing, high-performance computing (HPC), and database applications.
The server offers flexible storage configurations with up to 12 x 3.5-inch drives or 24 x 2.5-inch drives, enabling tailored solutions for different capacity and performance requirements. With 24 DDR4 memory DIMM slots supporting speeds up to 2933 MT/s and a maximum capacity of 3TB, the 2288X V5 can handle memory-intensive applications with ease.
Network connectivity is robust, featuring onboard dual 10GE ports and flexible OCP 2.0 mezzanine card options. The system is managed through the integrated Huawei iBMC management chip, which provides comprehensive remote administration capabilities including HTML5/VNC KVM, Redfish, SNMP, and IPMI 2.0 support. The server operates reliably in environments ranging from 5°C to 45°C, meeting ASHRAE A3 and A4 standards.
Full Specification List
| Category | Specification |
|---|---|
| Form Factor | 2U Rack-mount |
| Processors | 1 or 2 x 1st Gen Intel® Xeon® Scalable processors (3100/4100/5100/6100/8100 series, up to 205W); 1 or 2 x 2nd Gen Intel® Xeon® Scalable processors (3200/4200/5200/6200/8200 series, up to 205W) |
| Processor Socket | 2 sockets |
| Chipset | Intel C622 |
| Memory Type | DDR4 |
| Memory Speed | Up to 2933 MT/s |
| Memory Slots | 24 DIMM slots |
| Max Memory Capacity | 3TB |
| Memory Options | Standard DDR4 memory; supports up to 12 DCPMM modules at 2666 MT/s |
| Storage Interface | SATA, SAS, SSD |
| Internal Drive Bays (3.5″ chassis) | Up to 12 x 3.5″ SAS/SATA drives |
| Internal Drive Bays (2.5″ chassis) | Up to 24 x 2.5″ drives |
| Hot-swap Support | Supported |
| Disk Controller Options | SR130 or Broadcom® MegaRAID Tri-Mode SAS3508 |
| RAID Support | RAID 0, 1, 10, 1E, 5, 50, 6, 60; Cache supercapacitor protection, RAID level migration, disk roaming, self-diagnostics, web remote configuration |
| Expansion Slots | Up to 11 PCIe 3.0 slots: 8 standard slots, 1 RAID mezzanine slot, 2 OCP 2.0 mezzanine slots |
| Network Ports | Onboard: 2 x 10GE ports; Flexible mezzanine: 2 x 25G OCP 2.0 |
| Network Controller | Intel X722 integrated Ethernet connection for 10GbE SFP+ (dual-port) |
| GPU Support | Up to 8 x half-height/half-length GPU cards or 2 x full-width/full-length GPU cards |
| Cooling | 4 hot-swap counter-rotating fans, N+1 redundancy |
| Management | Huawei iBMC chip with dedicated GE management port; supports Redfish, SNMP, IPMI 2.0; HTML5/VNC KVM; Agentless deployment |
| Management Software (Optional) | Huawei eSight or FusionDirector – stateless computing, OS batch deployment, automated firmware updates, full lifecycle management |
| Power Supplies | Up to 2 redundant hot-swap power supplies (1+1 redundancy); Options: 550W AC Platinum, 900W AC Platinum/Titanium, 1500W AC Platinum, 1500W 380V HVDC, 1200W -48V~-60V DC |
| Video Adapter | Huawei Hi1710 integrated graphics |
| Security Features | Power-on password, administrator password, TPM 2.0, security bezel |
| Certifications | CE, UL, FCC, CCC, RoHS |
| Chassis Dimensions (3.5″ HDD) | 86.1 x 447 x 748 mm (H x W x D) |
| Chassis Dimensions (2.5″ HDD) | 86.1 x 447 x 708 mm (H x W x D) |
| Operating Temperature | 5°C to 45°C (41°F to 113°F); Complies with ASHRAE A3 and A4 standards |
| OS Support | Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, CentOS, Citrix XenServer, VMware ESXi |
Document Checklist for Huawei FusionServer Pro 2288X V5
The following product documents and resources are available for the 2288X V5 server:
| Document / Resource Type | Description |
|---|---|
| Quick Start Guide | Hardware setup and initial configuration instructions |
| User Guide | Comprehensive operational guidance for the FusionServer Pro 2288X V5 |
| Technical Specifications | Complete hardware specifications and capabilities |
| Hardware Installation Guide | Physical installation and cabling procedures |
| iBMC Management User Guide | Remote management and monitoring via the built-in management chip |
| RAID Configuration Guide | Storage array setup and management instructions |
| OS Installation Guide | Supported OS installation procedures |
| Safety Information | Safety warnings and regulatory compliance information |
| SUSE YES Certified Bulletin | Certified configuration for SUSE Linux Enterprise Server 12 SP5 with Intel Xeon Gold 6248 processors |
| SUSE YES Certified Bulletin | Certified configuration for SUSE Linux Enterprise Server 12 SP5 with Intel Xeon Platinum 8170 processors |
| Technical Support Portal | Huawei enterprise support resources and downloads |
