Huawei FusionServer RH5885 V3 Product Documentation
Product Overview
The Huawei FusionServer RH5885 V3 is a high-performance, 4U four-socket rack server designed for mission-critical enterprise workloads. Powered by Intel Xeon E7-4800/8800 v2, v3, or v4 series processors, it delivers up to 72 computing cores and supports up to 3TB of DDR4 memory across 48 DIMM slots. This server is purpose-built for demanding applications including databases, ERP systems, business intelligence analytics, big data processing, and virtualization environments.
The RH5885 V3 features comprehensive RAS (Reliability, Availability, Serviceability) capabilities, including chip-level fault tolerance, memory mirroring and sparing, and hot-swappable components for critical parts such as power supplies, fans, and hard drives. It supports PCIe 3.0 expansion with up to 8 PCIe slots and flexible storage configurations accommodating either 8 or 23 2.5-inch drives, with optional NVMe SSD support for accelerated I/O performance.
Designed for energy efficiency, the server incorporates dynamic power management, power capping capabilities, and platinum-rated power modules achieving up to 94% energy efficiency. With comprehensive remote management features including IPMI 2.0, KVM over IP, and support for third-party management integrations, the RH5885 V3 provides a robust, scalable foundation for enterprise data center deployments.
Product Specifications
| Category | Specification |
|---|---|
| Form Factor | Rack-mountable, 4U chassis |
| Dimensions (W x D x H) | 447 mm x 790 mm x 175 mm |
Processor
| Category | Specification |
|---|---|
| Processor Family | Intel Xeon E7-4800/8800 v2, v3, or v4 series |
| Maximum CPUs | 4 sockets |
| Max Cores per System | 72 cores |
| Bus Specification | QPI up to 6.4 GT/s |
| Process Technology | 14nm (v4) / 22nm (v3) |
Memory
| Category | Specification |
|---|---|
| Memory Type | DDR4 (v4) / DDR3 (v2/v3) |
| Memory Slots | 48 DIMM slots |
| Maximum Memory Capacity | 3TB |
| Memory Features | Memory mirroring, memory sparing, SDDC, DDDC |
Storage
| Category | Specification |
|---|---|
| Drive Interface | SAS, SATA, SSD |
| Internal Drive Bays | 8 or 23 x 2.5-inch drives; optional 8 x 2.5-inch + 4 x NVMe SSD |
| Hot-swap Support | Yes |
| RAID Support | RAID 0, 1, 10, 5, 50, 60 (controller dependent) |
| Disk Controller | SR430C with 1GB Cache (optional variants) |
Expansion & I/O
| Category | Specification |
|---|---|
| PCIe Slots | Up to 8 x PCIe 3.0 expansion slots (including 1 dedicated slot for RAID controller) |
| Network Controller | Optional 2 x GE, 4 x GE, or 2 x 10GE |
Management
| Category | Specification |
|---|---|
| Management Processor | Integrated BMC management module |
| Management Protocols | IPMI 2.0, SNMP v3, SNMP Trap v1, CIM, WS-MAN |
| Management Interfaces | GUI web interface, CLI, IPMI tools, virtual KVM, SOL, virtual media |
| Third-party Integration | Huawei eSight, VMware vCenter, Microsoft SystemCenter, Nagios |
| Diagnostic Features | LED diagnostic panel, black box function |
Cooling
| Category | Specification |
|---|---|
| Cooling Fans | 5 hot-swappable counter-rotating fans |
| Fan Redundancy | N+1 redundant |
Power
| Category | Specification |
|---|---|
| Power Supply Type | Hot-swappable redundant power modules |
| Power Redundancy | 1+1 or 2+2 redundant |
| Power Supply Count | 2 or 4 units |
| Power Rating | 1200W typical |
| Input Voltage | 110V/220V AC or -48V DC |
| Efficiency | Platinum-rated, up to 94% efficiency |
| Power Management | Dynamic frequency/voltage scaling, power capping |
Operating Environment
| Category | Specification |
|---|---|
| Operating Temperature | 5°C to 40°C |
Supported Operating Systems
| Category | Specification |
|---|---|
| Supported OS | Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, Citrix XenServer, VMware ESXi, Huawei FusionSphere |
