Dell PowerEdge R750xs Rack Server — Product Datasheet
Product Overview
The Dell PowerEdge R750xs is a 2U, dual-socket rack server purpose-built for scale-out environments. It is designed to deliver enterprise-class performance with a balanced selection of CPU, I/O, and storage capabilities tailored to growing workloads. Powered by 3rd Generation Intel® Xeon® Scalable processors with up to 32 cores per socket, the R750xs supports up to 1 TB of DDR4 memory at speeds up to 3200 MT/s, along with flexible storage configurations ranging from 2.5-inch NVMe drives to 3.5-inch SAS/SATA HDDs. With PCIe Gen4 expansion slots and OCP 3.0 networking options, the R750xs is well-suited for virtualization, medium-density VM/VDI deployments, and software-defined storage nodes.
Technical Specifications
| Feature | Specification |
|---|---|
| Form Factor | 2U rack server |
| Processor | Up to two 3rd Generation Intel® Xeon® Scalable processors, up to 32 cores per processor |
| Chipset | Intel C620 series chipset |
| Memory | 16 DDR4 DIMM slots; RDIMM only; up to 1 TB max; speeds up to 3200 MT/s |
| Storage Bays (Front) | 0 drive bays; up to 8 x 3.5″ SAS/SATA (HDD/SSD), max 128 TB; up to 12 x 3.5″ SAS/SATA (HDD/SSD), max 192 TB; up to 8 x 2.5″ SAS/SATA/NVMe (HDD/SSD), max 61.44 TB; up to 16 x 2.5″ SAS/SATA (HDD/SSD), max 122.88 TB; up to 16 x 2.5″ SAS/SATA + 8 x 2.5″ NVMe (HDD/SSD), max 184.32 TB |
| Storage Bays (Rear) | Up to 2 x 2.5″ SAS/SATA (HDD/SSD), max 15.36 TB |
| Storage Controllers — Internal | PERC H345, PERC H355, PERC H745, PERC H755, PERC H755N, HBA355i |
| Storage Controllers — External | PERC H840, HBA355e |
| Software RAID | S150 |
| Internal Boot | Boot Optimized Storage Subsystem (BOSS-S2): HWRAID 2 x M.2 SSD (240 GB or 480 GB); Dual internal SD module; USB |
| PCIe Slots | Up to 5 x PCIe Gen4 slots + 1 x PCIe Gen3 slot. Configurations include: 3 x16 Gen4 (x16 connector), full height, half length; 1 x4 Gen3 (x8 connector), full height, half length; 2 x16 Gen4 (x16 connector), full height, full length (optional) |
| Network Options | 2 x 1 GbE LOM; 1 x OCP 3.0 |
| Front Ports | 1 x dedicated iDRAC Direct micro-USB; 1 x USB 2.0; 1 x VGA |
| Rear Ports | 1 x USB 2.0; 1 x USB 3.0; 1 x serial (optional); 2 x Ethernet; 1 x VGA |
| Internal Ports | 1 x USB 3.0 (optional) |
| Video | 1 x VGA |
| Power Supplies | 600 W Platinum (100–240 VAC or 240 VDC), hot-swap redundant; 800 W Platinum (100–240 VAC or 240 VDC), hot-swap redundant; 1100 W DC (-48 to -60 V); 1100 W Titanium (100–240 VAC or 240 VDC), hot-swap redundant; 1400 W Platinum (100–240 VAC or 240 VDC), hot-swap redundant |
| Operating Systems | Canonical Ubuntu Server LTS; Citrix Hypervisor; Microsoft Windows Server with Hyper-V; RedHat Enterprise Linux; SUSE Linux Enterprise Server; VMware ESXi |
| Management | iDRAC9, iDRAC Direct, iDRAC RESTful API with Redfish, iDRAC Service Module, Quick Sync 2 wireless module |
| Security | Cryptographically signed firmware, Secure Boot, Secure Erase, Silicon Root of Trust, System Lockdown (requires iDRAC9 Enterprise or Datacenter), TPM 1.2/2.0, FIPS, CC-TCG certified, TPM 2.0 China NationZ |
| Dimensions (H x W x D) | 86.80 mm x 482.0 mm x 707.78 mm (without bezel); depth 721.62 mm (with bezel) |
| Weight | Max 28.60 kg (63.00 lb) |
