Dell PowerEdge T440 Tower Server — Product Dossier

Product Overview

The Dell PowerEdge T440 is a dual-socket, 5U rackable tower server designed for small to mid-sized businesses (SMBs) and remote office/branch office (ROBO) environments. It combines scalable performance with a compact, quiet form factor suited for office or data center deployment. The T440 supports up to two Intel Xeon Scalable processors, substantial DDR4 memory capacity, and flexible storage configurations to handle a wide range of workloads including collaboration, mail and messaging, file and print serving, web serving, database applications, and server virtualization.

Key design priorities include a short 22-inch chassis depth, quiet acoustics, and tool-less access for serviceability. The platform offers five PCIe Gen 3 expansion slots, hot-plug drive bays, redundant power supply options, and comprehensive systems management through iDRAC9 with Lifecycle Controller.

Technical Specifications

Category Specification
Form Factor 5U Tower or Rack-mountable
Processor Up to two 2nd Generation Intel Xeon Scalable processors; up to 28 cores per processor (up to 16 cores per processor per some datasheets)
Chipset Intel C620 Series
Memory 16 DDR4 DIMM slots; Supports RDIMM and LRDIMM; Speeds up to 2666 MT/s; Registered ECC DDR4 DIMMs only
Maximum RAM RDIMM: 512 GB; LRDIMM: 1 TB
Storage – Front Bays Up to 4 or 8 × 3.5″ SAS/SATA (HDD/SSD); Up to 16 × 2.5″ SAS/SATA (HDD/SSD)
Storage Controllers (Internal) PERC H330, H730p, H740p, HBA330; Software RAID S140
Storage Controllers (External) H840 (PERC RAID); 12 Gbps SAS HBA (non-RAID)
Boot Optimized Storage HWRAID 2 × M.2 SSDs (120 GB or 240 GB)
PCIe Slots 2 × Gen3 x4; 2 × Gen3 x8; 1 × Gen3 x16 (Total: 5 slots)
GPU / Accelerator Up to 1 × NVIDIA Quadro P4000 (APOS/customer kit only)
Network Options 2 × 1GbE LOM (standard); Optional LOM Riser: 2 × 1GbE, 2 × 10GbE SFP, or 2 × 10GbE BaseT
Front Ports 1 × Dedicated iDRAC Direct USB; 1 × USB 2.0; 1 × USB 3.0 (optional); 1 × Video
Rear Ports 1 × Dedicated iDRAC network port; 1 × Serial; 2 × USB 3.0; 1 × Video
Power Supplies 450W Gold (cabled); 495W Platinum; 750W Platinum; 1100W Platinum; Up to 2 hot-plug PSUs with full redundancy
Cooling Internal fan; Optional external fan at rear of chassis
Management iDRAC9 with Lifecycle Controller; iDRAC Direct; iDRAC RESTful API with Redfish
Systems Management Tools OpenManage Enterprise; OpenManage Power Center; OpenManage Mobile; RACADM CLI; Repository Manager; System Update; Server Update Utility; IPMI Tool; OpenManage Server Administrator
Supported Operating Systems Canonical Ubuntu Server LTS; Citrix Hypervisor; Microsoft Windows Server with Hyper-V; Red Hat Enterprise Linux; SUSE Linux Enterprise Server; VMware ESXi
Security TPM 1.2/2.0 (optional); Cryptographically signed firmware; Secure Boot; System Lockdown; System Erase; Silicon Root of Trust
Dimensions (H × W × D) 430.3 mm × 218 mm (304.5 mm with base) × 594.82 mm
Weight (Max) 23 kg (4 × 3.5″ configuration); 29.3 kg (8 × 3.5″ configuration); 27.7 kg (16 × 2.5″ configuration)
