Huawei CloudEngine CE6885-SAN-56F Data Center Storage Network Switch – Product Documentation

Name: Huawei CloudEngine CE6885-SAN-56F - Refurbished & Tested - SunSpike
Brand: HUAWEI
SKU: CE6885-SAN-56F

Product Overview

The Huawei CloudEngine CE6885-SAN-56F is a next-generation, high-density 10GE/25GE/50GE access switch purpose-built for all-flash storage networks in modern data centers . Designed to address the performance demands of NVMe storage, this switch provides high-density 40GE/100GE/200GE uplink ports within a compact 1U form factor.

At the heart of its design is Huawei’s exclusive iLossless intelligent algorithm, which eliminates packet loss on traditional Ethernet networks, creating a zero-packet-loss, low-latency, and high-throughput environment critical for RoCEv2 applications . This capability, combined with support for iNOF (intelligent NOF) technology, enables plug-and-play storage network deployment, rapid fault detection, and sub-second active/standby server switchover .

The switch features flexible airflow direction selection (front-to-back or back-to-front), redundant power supplies (1+1), and N+1 redundant hot-swappable fans, making it suitable for diverse data center deployment scenarios . It can be deployed alongside Huawei CloudEngine 8850-SAN or CloudEngine 16800-X switches to build intelligent lossless Data Center Networks (DCNs) that fully unlock the potential of all-flash storage infrastructure .

Product Specifications

Category	Parameter	Specification
Model	Product Model	CloudEngine 6885-SAN-56F
	Part Number	02355KTW
	Chassis Type	1U rack-mountable
Ports	Downlink Ports	48 × 25GE SFP28 / 48 × 50GE SFP56 (backward compatible with 10GE, switchable to GE)
	Uplink Ports	8 × 100GE QSFP28 / 8 × 200GE QSFP56 (each 100GE port supports 40GE mode; each 200GE port auto-senses to 40GE/100GE)
	Port Upgrade (RTU)	25GE → 50GE; 100GE → 200GE via RTU license
	Port Splitting	100GE QSFP28 can split into 4 × 25GE SFP28 or 4 × 10GE SFP+
Performance	Switching Capacity	8 Tbps (48×50GE + 8×200GE)
	Forwarding Rate	2400 Mpps
	Buffer	36 MB / 64 MB
Hardware	CPU	4-core, 1.4 GHz
	Memory (DRAM)	8 GB
	NOR Flash	64 MB
	SSD Flash	4 GB
	Management Ports	1 × Console (RJ-45), 1 × ETH management port (RJ-45), 1 × USB
Power	Power Supply Modules	600 W AC & 240 V DC; 1200 W DC
	Redundancy	1+1 hot-swappable
	Operating Voltage (AC)	90 V AC to 290 V AC, 45 Hz to 65 Hz
	Operating Voltage (HVDC)	190 V DC to 290 V DC
	Operating Voltage (DC)	–38.4 V DC to –72 V DC; +38.4 V DC to +60 V DC
	Typical Power (25G+100G)	147 W (24×25G+4×100G copper, normal temp, dual AC)
	Typical Power (25G+100G, optics)	166 W (24×25G+4×100G short-reach optics, normal temp, dual AC)
	Typical Power (50G+200G)	177 W (24×50G copper + 4×200G short-reach optics, normal temp, dual AC)
	Maximum Power	Up to 328 W (full load, long-reach optics, high temperature)
Cooling	Fan Modules	5 × hot-swappable (N+1 redundancy, 4+1 backup)
	Airflow Direction	Port-side intake or port-side exhaust (selectable via fan/power modules)
	Noise (Normal Temp)	Front-to-back: avg 52.8 dB(A); Back-to-front: avg 51.3 dB(A)
	Noise (High Temp)	Front-to-back: avg 69.5 dB(A); Back-to-front: avg 70.2 dB(A)
Physical	Dimensions (H×W×D)	43.6 mm × 442 mm × 420 mm (1U)
	Weight (Full Config)	8.55 kg
Environment	Operating Temperature	0°C to 40°C (0–1800 m altitude)
	Storage Temperature	–40°C to +70°C
	Operating Humidity	5% RH to 95% RH (non-condensing)
	Long-term Operating Altitude	≤ 5000 m
Reliability	High Availability Features	LACP, Hardware BFD (min 3.3ms interval), DPFR
	Availability	0.9999948505
	MTBF	44.34 years
Data Center Features	Virtualization	VXLAN routing and bridging, BGP-EVPN, M-LAG
	Time Synchronization	IEEE 1588v2 (PTP)
	Security	MACsec, port isolation, IP-MAC-port-VLAN binding, AAA/RADIUS/HWTACACS
Intelligent Lossless Network	iLossless Algorithm	AI ECN, PFC Deadlock Prevention, iNOF, ECN Overlay, NPCC
O&M	Telemetry	Netstream, Enhanced ERSPAN, IFIT, Packet Event (loss/latency visualization)
	Automated O&M	ZTP (Zero Touch Provisioning), Ansible support, NETCONF
	Network-wide Path Detection	VXLAN ping/tracert, IFIT
Security Compliance	Safety Standards	EN 62368-1, IEC 62368-1, UL 62368-1, CSA-C22.2 No.62368-1, AS/NZS 62368-1, GB4943
	EMC Standards	EN 300386, EN 55032, EN 55035
