Huawei CloudEngine S5751-L8T2J-RUA Product Documentation

Name: Huawei CloudEngine S5751-L8T2J-RUA - Refurbished & Tested - SunSpike
Brand: HUAWEI
SKU: S5751-L8T2J-RUA

Product Overview

The Huawei CloudEngine S5751-L8T2J-RUA is a 10GE uplink remote unit switch designed as part of Huawei’s innovative streamlined campus network architecture. Based on Huawei’s proprietary “Asteroid” lean architecture, this switch simplifies the traditional three-layer network model (access, aggregation, core) into a two-layer architecture with only access and core layers, significantly reducing network deployment and management complexity .

This remote unit functions as a port expansion module for central switches such as the Huawei S6700/S5700 series, enabling flexible port scaling without complex reconfiguration . The S5751-L8T2J-RUA provides GE data access capabilities and supports multiple deployment scenarios including enterprise offices, educational institutions, hotels, and healthcare facilities .

The device features a fanless design with natural heat dissipation, achieving ultra-low power consumption with an average maximum power consumption of less than 1W per port, delivering approximately 30% energy savings compared to traditional switches . Supporting both desk and wall-mounting options, this switch offers flexible installation to meet various site requirements .

Technical Specifications

Category	Specification
Model	CloudEngine S5751-L8T2J-RUA
Product Series	CloudEngine S5751-L Remote Unit Switches
Downlink Ports	8 × 10/100/1000 Base-T ports
Uplink Ports	2 × 100M/1/2.5GE SFP ports
Switching Capacity	98 Gbps
Forwarding Performance	19.5 Mpps
Power Supply Type	External power adapter
Rated Input Voltage	100V AC to 240V AC; 50/60 Hz (adapter input) / 12V DC (adapter output)
Maximum Power Consumption	7.46W (device) / 10.93W (device + adapter)
Typical Power Consumption	10.52W
Static Power Consumption	4.85W
PoE Support	Not supported
Cooling / Noise	Fanless, natural heat dissipation, zero noise
Dimensions (H × W × D)	35mm × 195mm × 130mm
Weight (without packaging)	0.83 kg
Weight (with packaging)	1.28 kg
Installation Methods	Desk mounting or Wall mounting
Ingress Protection Level	IP20
Operating Temperature	-5°C to +45°C
Storage Temperature	-40°C to +70°C
Operating Relative Humidity	5% to 95%, non-condensing
Storage Relative Humidity	5% to 95%, non-condensing
Operating Altitude	0 to 5000 meters
Surge Protection (Power Port)	Differential mode: ±4 kV; Common mode: ±6 kV
Management	Web, CLI, SNMP, Cloud management (iMaster NCE)
QoS Support	Yes (802.1p, DSCP, traffic shaping, queue scheduling)
LED Indicators	Power, Status, Port indicators
Chassis Material	Metal
