IBM FC:EC30 P/N:00E1599

SKU： 00E1599 分类： 品牌： ,

Here is the detailed technical specification and overview for the IBM 00E1599 network adapter.

IBM 00E1599 Overview

The IBM 00E1599 (Feature Code EC30) is a high-performance, enterprise-grade PCIe Generation 2.0 x8 dual-port 10GbE (10 Gigabit Ethernet) RoCE (RDMA over Converged Ethernet) SR (Short Range) SFP+ network adapter.

This hardware utilizes an optical/SFP+ transceiver architecture optimized for extreme throughput and low-latency environments. Built upon Mellanox ConnectX-2 technology (specifically the MNPH29D-XTR / MNPH29D-XSR ASIC design), this adapter is specifically manufactured to handle heavy storage clustering, high-frequency database workloads, and high-performance computing (HPC) inside IBM Power Systems environments.

Technical Specifications

Parameter Specification
IBM Part Number (P/N) 00E1599
IBM Feature Code (FC) EC30
Associated FRU P/N 00E1601 (often paired/interchangeable with 00E1856)
Original ASIC / Architecture Mellanox ConnectX-2 technology platform
Interface / Bus Type PCI Express 2.0 x8
Ports Dual-port (2 x SFP+ slots)
Data Rate 10 Gbps per port (Line rate)
Form Factor Full-Height bracket configuration (also available in low-profile options)
Physical Media Standard Optical Fiber / 10GBase-SR

Key Features & Protocol Support

  • RoCE (RDMA over Converged Ethernet): Delivers Remote Direct Memory Access (RDMA) over standard Ethernet infrastructure. It allows data transmission directly between the memory spaces of compute nodes without involving the host operating system’s network stack, which drastically slashes CPU overhead and latency.

  • SR Optical Capabilities: Designed for Short Range (SR) fiber multi-mode environments. When loaded with 10GbE SR SFP+ transceivers, it transmits data flawlessly via OM3/OM4 fiber cables.

  • Stateless Offloads:

    • TCP/UDP/IP Checksum Offload

    • Large Send Offload (LSO) / Large Receive Offload (LRO)

    • Receive Side Scaling (RSS)

  • Data Center Bridging (DCB): Supports enhanced transmission selection, congestion notification, and priority-based flow control (PFC) to enable a completely lossless Ethernet canvas required for high-grade RoCE implementation.

System Compatibility

Supported Systems

This adapter is natively designed for enterprise-level scale-out and scale-up IBM Power Systems, specifically within:

  • IBM Power8 Systems

  • IBM Power7+ Systems

Operating System Support

  • IBM AIX (Specific Service Pack versions required for full RoCE utility)

  • IBM i

  • Red Hat Enterprise Linux (RHEL)

  • SUSE Linux Enterprise Server (SLES)

  • VIOS (Virtual I/O Server)
