Huawei S5700-28TP-PWR-LI-AC – Product Datasheet

Name: Huawei S5700-28TP-PWR-LI-AC Switch - SunSpike
SKU: S5700-28TP-PWR-LI-AC

Product Overview

The Huawei S5700-28TP-PWR-LI-AC is a next-generation energy-saving gigabit Ethernet switch designed for enterprise network environments. As a fully managed Layer 3 switch, it delivers high-performance switching capacity with a backplane bandwidth of 256 Gbps/2.56 Tbps and a packet forwarding rate of 66 Mpps/96 Mpps.

The switch features 24 PoE+ 10/100/1000BASE-T ports, providing Power over Ethernet Plus capability to power connected devices such as IP phones, wireless access points, and surveillance cameras. It also includes two 1000BASE-X uplink optical ports and two combo ports (10/100/1000BASE-T + 100/1000BASE-X) for flexible network connectivity. With support for VLAN, QoS, multicast management, network management, and security features, the S5700-28TP-PWR-LI-AC is a versatile solution for small to medium-sized enterprise deployments.

The switch supports PoE+ with a total PoE power budget of 370W, enabling efficient power delivery to multiple endpoints simultaneously. Its compact 1U form factor (442 × 310 × 43.6 mm) allows for easy installation in standard equipment racks. The device also features an RPS (Redundant Power Supply) socket for power backup, enhancing network reliability.

Technical Specifications

Category	Specification
General
Product Type	Gigabit Ethernet switch
Application Layer	Layer 3
Switching Mode	Store-and-forward
Ports
Total Ports	30 ports
Fixed Ports	24 × PoE+ 10/100/1000BASE-T Ethernet ports
Uplink Ports	2 × 1000BASE-X optical ports (non-combo)
Combo Ports	2 × combo ports (10/100/1000BASE-T + 100/1000BASE-X)
Console Port	1 × console port
Management Port	1 × mini USB port
Performance
Backplane Bandwidth	256 Gbps / 2.56 Tbps
Packet Forwarding Rate	66 Mpps / 96 Mpps
MAC Address Table	16K
Power over Ethernet
PoE Standard	PoE+ supported
PoE Power Budget	370W
Power Supply
AC Input Voltage (Rated)	100 V AC to 240 V AC, 50/60 Hz
AC Input Voltage (Max Range)	90 V AC to 264 V AC, 47/63 Hz
DC Input Voltage (Rated)	-48 V DC to -60 V DC
DC Input Voltage (Max Range)	-36 V DC to -72 V DC
Maximum Power Consumption (AC)	< 469.7 W (PoE: 370 W)
RPS Support	RPS socket for redundant power supply backup
Physical Specifications
Dimensions (W × D × H)	442 × 310 × 43.6 mm (17.40 × 12.20 × 1.72 in)
Weight	9.6 kg (21.16 lb)
Environmental Specifications
Operating Temperature	0°C to 50°C (32°F to 122°F)
Operating Humidity	5% to 95% (non-condensing)
