Huawei S2720-12TP-PWR-EI-AC – Product Documentation & Specifications

Name: Huawei S2720-12TP-PWR-EI-AC Switch - SunSpike
SKU: S2720-12TP-PWR-EI-AC

Product Overview

The Huawei S2720-12TP-PWR-EI-AC is an enterprise-grade Layer 3 Gigabit Ethernet switch from Huawei’s S2720-EI series. It is a next-generation 100M intelligent access switch designed primarily for enterprise campus access scenarios, featuring both 100M-to-the-desktop and Gigabit Ethernet (GE) uplink transmission capabilities.

Powered by Huawei’s Versatile Routing Platform (VRP) software and advanced switching technologies, this switch delivers a rich set of Layer 3 routing protocols including static routing, RIP, RIPng, and OSPF, offering leading routing performance in the 100M switch field. The S2720-12TP-PWR-EI-AC provides a versatile mix of 100M and 1000M ports with PoE+ support, making it suitable for powering connected devices such as IP phones, wireless access points, and surveillance cameras directly through the Ethernet cables.

Key capabilities include support for Intelligent Stacking (iStack), which improves device reliability and scalability while significantly reducing operations and maintenance (O&M) costs through unified configuration and management of the entire stack system. The switch also supports flexible VLAN deployment, comprehensive security and QoS policies, and energy-saving technologies such as IEEE 802.3az Energy-Efficient Ethernet (EEE), helping enterprise customers build next-generation IT networks with lower operational costs.

The switch can also operate as a client in a Super Virtual Fabric (SVF) system, enabling simplified network management and architecture.

Documentation List

Document / Resource	Description
S2720-EI Series Switches Datasheet	Comprehensive product overview, key features, and technical specifications for the entire S2720-EI series
S2720-12TP-PWR-EI-AC Installation Guide	Hardware installation procedures, mounting options, and initial setup instructions
S2720-EI Series Configuration Guide	Detailed CLI configuration guidance for VLANs, routing, QoS, security, and management features
S2720-EI Series Command Reference	Complete command-line interface (CLI) command reference for all supported features
S2720-EI Series Quick Start Guide	Brief setup guide for rapid deployment and basic configuration
S2720-EI Series Safety Instructions	Safety information, regulatory compliance, and environmental specifications
S2720-EI Series MIB Reference	Management Information Base (MIB) files for SNMP network management integration

Technical Specifications

Category	Specification
General
Product Model	S2720-12TP-PWR-EI-AC
Product Type	Enterprise-class switch
Application Layer	Layer 3
Switching Capacity	68 Gbit/s
Forwarding Performance	12.6 Mpps
MAC Address Table	16K MAC address entries, configurable aging time, blackhole MAC address entries, limit on number of MAC addresses learned on a port
Ports & Interfaces
Total Ports	12 ports
Fixed Downlink Ports	4 × 10/100 Base-TX Ethernet ports
Fixed Downlink Ports	4 × 10/100/1000 Base-T Ethernet ports
Fixed Uplink Ports	2 × Gigabit SFP ports
Fixed Uplink Ports	2 × Combo Gigabit ports (10/100/1000 Base-T or SFP)
Extended Slot	Not available
Transmission Mode	Full-duplex / Half-duplex auto-negotiation
Switching Method	Store-and-forward
Power
Power Supply Type	Fixed AC power
Rated Voltage Range	100-240V AC; 50-60Hz
Maximum Voltage Range	90-264V AC; 47-63Hz
Maximum Power Consumption (without PoE)	15.61W
Maximum Power Consumption (with PoE)	160.5W (PoE budget: 123.2W)
PoE Support	PoE+
VLAN
Active VLANs	4K
VLAN Features	Guest VLAN, Voice VLAN, GVRP, MUX VLAN
VLAN Assignment Methods	MAC address-based, protocol-based, IP subnet-based, policy-based, interface-based
VLAN Mapping	1:1 and N:1 VLAN Mapping
IP Routing
Routing Protocols	Static routing, RIP, RIPng, OSPF
IPv6
IPv6 Features	Neighbor Discovery (ND), Path MTU (PMTU), IPv6 ping, IPv6 tracert, IPv6 Telnet
DHCPv6	DHCPv6 Relay, DHCPv6 Server, DHCPv6 Snooping
Multicast
Multicast Management	IGMP v1/v2/v3 Snooping, controllable multicast, interface-based multicast traffic statistics, MLD v1/v2 Snooping
QoS / ACL
Queue Support	8 queues per port
Queue Scheduling Algorithms	WRR, DRR, SP, WRR+SP, DRR+SP
QoS Features	Rate limiting by interface, re-marking of 802.1p priority and DSCP priority, rate limiting in each queue, traffic shaping on interfaces
Security
Security Features	Port isolation, port security, sticky MAC
	MFF (MAC Forced Forwarding)
	Blackhole MAC address entries, limit on number of learned MAC addresses
Authentication	IEEE 802.1X authentication, AAA authentication, RADIUS, HWTACACS, NAC
	SSH V2.0, HTTPS
	CPU protection, blacklist and whitelist
DHCP Security	DHCP Relay, DHCP Server, DHCP Snooping
Reliability & Protection
Ethernet Loop Protection	RRPP ring topology and multi-instance, Smart Link tree topology and multi-instance (millisecond-level protection switchover), SEP, ERPS (G.8032)
Spanning Tree Protocols	STP (IEEE 802.1d), RSTP (IEEE 802.1w), MSTP (IEEE 802.1s)
OAM	EFM OAM (802.3ah), CFM OAM (802.1ag), ITU-Y.1731, DLDP, LACP
Network Management
Management Features	Intelligent Stacking (iStack), Virtual Cable Test
	Telnet remote configuration and maintenance
	SNMP v1/v2c/v3, RMON
	eSight network management system, Web-based management
	HTTPS, LLDP/LLDP-MED
	System logs, hierarchical alarms
Energy Efficiency	IEEE 802.3az Energy-Efficient Ethernet (EEE)
Physical & Environmental
Dimensions (W × D × H)	320 × 220 × 43.6 mm
Operating Temperature	0°C to 45°C
Relative Humidity	5% to 95% (non-condensing)
