Huawei S12712 Switch – Product Documentation

Name: Huawei S12712 Switch - SunSpike
SKU: S12712

Product Overview

The Huawei S12712 is a core switch from the S12700 series of Agile Switches, designed for next-generation high-quality campus networks. Built on a fully programmable switching architecture, the S12712 enables fast, flexible function customization and supports a smooth evolution to Software-Defined Networking (SDN).

The switch features a highly reliable CLOS architecture with separated system control boards and switching boards, allowing SFUs to be configured on demand and upgraded in the future for smooth campus network evolution. Key components operate in redundancy mode to minimize risks of system breakdown and service interruption.

The S12712 integrates an industry-leading native Wireless Access Controller (AC) capability, managing up to 10,240 APs for unified wired and wireless network management. It also supports innovative features including VXLAN, free mobility, intelligent HQoS, iPCA, and SVF. The switch adopts a left-to-rear ventilation channel for improved energy efficiency.

The S12712 supports the innovative CSS2 hardware clustering technology, enabling 1+N backup of MPUs on modular core switches, ensuring that an MPU failure does not affect service data exchange of the entire system. All key components—including power supplies, fans, MPUs, LPUs, SFUs, and cluster cards—support hot-swapping.

Key Product Data

Item	Specification
Product Series	S12700 Series Agile Switches
Product Model	S12712
Product Type	Enterprise-Class Core Switch
Application Layer	Layer 3
Switching Architecture	CLOS architecture with separated control and switching planes
Chassis Height	19 U
Cooling Method	Left-to-rear ventilation
IP Rating	IP20

Detailed Specifications

Category	Parameter	Specification
Slots	MPU Slots	2
	SFU Slots	4
	LPU Slots	12
	CMU Slots	2
	Fan Slots	5
	Power Module Slots	6
Port Density (per chassis)	FE Ports	576
	GE Ports	576
	10GE Ports	576
	40GE Ports	96
	100GE Ports	48
Performance	Switching Capacity	17.44 Tbps / 37.28 Tbps
	Packet Forwarding Rate	9,120 Mpps / 12,960 Mpps
	Switching Mode	Store-and-Forward
Physical	Dimensions (H x W x D)	841.75 mm x 442 mm x 489 mm
	Chassis Height	19 U
	Weight (empty/full configuration)	64 kg / 159 kg
Power	Input Voltage	DC: -38.4 V to -72 V
		AC: 90 V to 290 V
	Maximum Power Consumption	6,790 W
Environment	Operating Temperature (0–1800 m)	0°C to 45°C
	Operating Temperature (1800–4000 m)	Decreases 1°C per 220 m altitude increase
	Operating Temperature (>4000 m)	0°C to 35°C
	Storage Temperature	-40°C to +70°C
	Relative Operating Humidity	5% RH to 95% RH, noncondensing
	Relative Storage Humidity	5% RH to 95% RH, noncondensing
	Noise (under normal temperature)	≤ 77.9 dB
Features	Virtualization	SVF 2.0 – virtualizes up to 4K clients into a single device
	Clustering	CSS2 switch fabric hardware clustering
	VLAN	Supports LNP, Access, Trunk, Hybrid modes
	Security & VPN	NAT, SSL VPN, IPSec, IPS
	Management	SNMPv1/v2c/v3, CLI, SSH v1.5/v2.0
	Hot-Swap Support	Power modules, fans, MPUs, LPUs, SFUs, cluster cards
	Redundancy	All key components support redundancy
Installation	Cabinet Type	N66E or N68E cabinet, one chassis per cabinet
