Name: HPE ProLiant DL580 Gen10 Server - SunSpike
SKU: DL580Gen10

HPE ProLiant DL580 Gen10 Server Specifications

The HPE ProLiant DL580 Gen10 Server is a high-density, four-socket (4P) 4U rack enterprise server designed for business-critical workloads, large-scale virtualization, database management, and data-intensive applications.

Technical Specifications Summary

Specification Category	Technical Details
Form Factor	4U Rackmount Chassis
Processor Support	Up to 4 x 1st or 2nd Generation Intel® Xeon® Scalable Processors (Platinum 8100/8200, Gold 6100/6200/5100/5200 series)
Processor Cores	4 to 28 cores per processor (up to 112 cores total per system); L3 Cache up to 38.5 MB
Memory Slots	48 DDR4 DIMM slots (12 DIMM slots per processor)
Memory Capacity	Up to 6.0 TB DDR4 (2933/2666 MT/s RDIMM/LRDIMM); Up to 12.0 TB with HPE Persistent Memory 100 Series
Storage Controllers	Embedded: HPE Smart Array S100i SATA RAID Essential: E208i-a, E208i-p, E208e-p Performance: P408i-a, P408i-p, P408e-p, P816i-a, P824i-p
Drive Bays	Up to 48 x SFF SAS/SATA HDDs/SSDs; Up to 20 x NVMe PCIe SSDs
Maximum Storage	Up to 115.2 TB (48 x 2.4 TB SAS SFF) / Up to 307.2 TB (48 x 6.4 TB NVMe SFF)
I/O Expansion Slots	Up to 16 PCIe 3.0 expansion slots (Full-Height/Full-Length options via primary, secondary, tertiary risers)
Networking	FlexibleLOM slot + PCIe Standup Adapters (1GbE, 10GbE, 25GbE, 40GbE, 100GbE options)
Management	HPE iLO 5 (Integrated Lights-Out), HPE OneView Standard/Advanced, HPE InfoSight
Power Supplies	Up to 4 x HPE Flexible Slot Power Supplies (800W / 1600W 96% Platinum/Titanium, -48VDC options); Redundant N+N or N+1
Security Features	HPE Silicon Root of Trust, Secure Boot, TPM 2.0, Chassis Intrusion Detection, AES/3DES Encryption

Key Features & Architecture Highlights

Four-Socket Scalability: Delivers computing power with support for 4 Intel Xeon Scalable CPUs in a 4U footprint.
Modular Storage Subsystem: Flex-bay chassis design allows customizable combinations of SAS/SATA drives and direct-attach NVMe PCIe SSDs.
Silicon Root of Trust Security: iLO 5 hardware security anchors firmware validation directly to the chip to protect against zero-day malware and firmware attacks.
High Expansion Bandwidth: Up to 16 PCIe 3.0 slots accommodate multi-GPU accelerators, high-speed storage controllers, and NIC expansion.
