Seagate Exos 7E10 10TB 3.5 7.2K SATA 6 Gb/s (SATA III)
ST10000NM017B
Enterprise stock · tested · export documentation available
Product Overview
-
Product Series: Seagate Exos® 7E10
-
Model Number: ST10000NM017B
-
Capacity: 10 TB
-
Form Factor: 3.5-inch Enterprise Internal HDD
Technical Specifications
| Feature / Parameter | Specification |
| Model Number | ST10000NM017B |
| Formatted Capacity | 10 TB |
| Form Factor | 3.5-inch |
| Interface | SATA 6 Gb/s (SATA III) |
| Sector Format | 512e / 4Kn (FastFormat™) |
| Recording Technology | Conventional Magnetic Recording (CMR) |
| Spindle Speed | 7,200 RPM |
| Cache / Buffer | 256 MB |
Performance & Reliability
| Performance Metric | Specification |
| Max Sustained Transfer Rate (OD) | Up to 263 MB/s |
| Average Latency | 4.16 ms |
| Rotational Vibration (RV) Sensors | Yes |
| Workload Rate Limit (WRL) | 550 TB / year |
| Mean Time Between Failures (MTBF) | 2,000,000 hours |
| Annualized Failure Rate (AFR) | 0.44% |
| Power-On Hours | 24×7 (8,760 hours/year) |
| Load/Unload Cycles | 600,000 |
| Non-Recoverable Read Errors | 1 sector per $10^{15}$ bits read |
| Limited Warranty | 5 Years |
Power & Environmental Specifications
| Parameter | Value / Range |
| Average Operating Power (Random Read) | ~10.8 W – 11.8 W |
| Idle Power (Average) | ~6.59 W – 7.8 W |
| Standby / Sleep Power | 0.8 W |
| Power Supply Requirements | +12 V and +5 V |
| Operating Temperature (Drive Reported) | 5°C to 60°C (41°F to 140°F) |
| Non-Operating Temperature | -40°C to 70°C (-40°F to 158°F) |
| Operating Shock (2ms Read/Write) | 70 G / 40 G |
| Non-Operating Shock (1ms / 2ms) | 150 G / 300 G |
| Acoustics (Idle / Seek) | 23 dBA / 27 dBA |
Physical Dimensions
| Dimension | Value |
| Height (Max) | 26.11 mm / 1.028 in |
| Width (Max) | 101.85 mm / 4.010 in |
| Depth (Max) | 147.00 mm / 5.787 in |
| Weight | ~690 g – 716 g / 1.52 lb – 1.58 lb |
