P09088-B21 HPE 400GB SAS 12G MIXED USE 2.5IN SC DS SSD P09922-001

HPE 400GB SAS 12Gbps Mixed Use SFF SC Digitally Signed Firmware SSD

Product Overview:

The P09088-B21 (with Option/Spare Part Number P09922-001) is an enterprise-class, high-performance 400GB Mixed Use (MU) Solid State Drive utilizing a 12Gbps Serial Attached SCSI (SAS) interface. Built in a 2.5-inch Small Form Factor (SFF) hot-plug carrier, this drive features HPE Smart Carrier (SC) packaging and Digitally Signed (DS) firmware. It is engineered for enterprise workloads requiring a balanced mix of high read and write performance, extreme reliability, and data security.

Key Technical Specifications

Parameter	Specification Details
HPE Option Part Number	P09088-B21
HPE Spare Part Number	P09922-001
Assembly Part Number	P06584-001, P04525-B21 (and equivalents)
Capacity	400 GB
Interface Type	Dual-Port SAS (Serial Attached SCSI)
Interface Speed	12 Gbps (Backward compatible with 6 Gbps SAS)
Workload Category	Mixed Use (MU)
Form Factor	2.5″ SFF (Small Form Factor)
Carrier Type	HPE Smart Carrier (SC)
Flash Memory Type	Multi-Level Cell (MLC) or Multi-Layer TLC Enterprise NAND
Firmware Security	Digitally Signed Firmware (DS)

Workload Endurance & Performance Data

Mixed Use drives are designed for environments with heavy read/write mixed workloads, offering robust endurance typically rated at 3 DWPD (Drive Writes Per Day) over a 5-year period.

• Endurance Total Bytes Written (TBW): ~2,190 TB

• Random Reads (4KiB): Up to 108,000 IOPS

• Random Writes (4KiB): Up to 47,000 IOPS

• Sequential Reads (128KiB): Up to 1,075 MB/s

• Sequential Writes (128KiB): Up to 1,025 MB/s

Core Technologies & Features

• HPE Smart Carrier (SC): Features self-describing LEDs that communicate the status of the drive (activity, online, predictive failure, do-not-remove status). This prevents accidental drive removal while data is being written.

• Digitally Signed (DS) Firmware: Provides an extra layer of security by ensuring all drive firmware comes from a trusted source (HPE). It actively prevents malicious attacks, unauthorized firmware modifications, and accidental corruption.

• Dual-Port High Availability: Utilizes dual-port SAS architecture to provide redundant data paths, ensuring no single point of failure between the server backplane/controller and the drive.

Hardware Compatibility

This drive is optimized for HPE ProLiant Gen9 and Gen10/Gen10 Plus enterprise servers as well as select HPE Apollo systems utilizing 2.5″ SFF hot-plug drive bays:

• HPE ProLiant DL Series: DL20, DL160, DL180, DL360, DL380, DL385, DL560, DL580 (Gen9 / Gen10 / Gen10 Plus)

• HPE ProLiant ML Series: ML30, ML110, ML350 (Gen9 / Gen10)

• HPE Synergy & Blade Systems: BL460c Gen10, Synergy 480/660 Gen10 Compute Modules

• HPE Storage Arrays: MSA series and D3700/D3710 enclosures supporting standard HPE Smart Carriers.
