Product Technical Specification Sheet

1. Product Identification

• Brand Name: HPE (Hewlett Packard Enterprise)

• Product Line: Mixed-Use (MU) Smart Carrier (SC) Enterprise SSD Family

• HPE Option Part Number: 802582-B21

• HPE Spare Part Number: 802599-001

• HPE Assembly Part Number: 802907-001

• OEM Underlying Hardware: SanDisk / Western Digital Corporation (Lightning Gen. II Series Matrix)

• HPE Model String: MO0400JFFCF

• Target Environment: High-performance database workloads, virtualization pools, heavy cloud-computing nodes, and mixed read/write caching layers.

2. Core Architectural Specifications

• Form Factor: 2.5-inch Small Form Factor (SFF)

• Drive Mechanical Thickness: 15.0 mm standard enterprise layout

• Formatted Capacity: 400 GB

• Interface Protocol: Dual-Port Serial Attached SCSI-3 (SAS 12Gb/s)

• Interface Link Speed: 12.0 Gbps (Backward compatible with 6.0 Gbps SAS host buses)

• NAND Flash Technology: Enterprise Multi-Level Cell (eMLC)

• Carrier Sled Type: HPE SmartCarrier (SC) hot-plug tray featuring an integrated digital status signaling ring.

• Sector Architecture: 512n (Native 512-byte block format)

3. Performance & Throughput Profiles

Optimized with highly sustained steady-state enterprise algorithms to balance high I/O throughput with predictable sub-millisecond latencies under concurrent workloads:

Performance Metric	Rated Specification
Sustained Sequential Read (128KB)	Up to 1,000 MB/s
Sustained Sequential Write (128KB)	Up to 580 MB/s
Random Read IOPS (4KiB, QD32)	Up to 125,000 IOPS
Random Write IOPS (4KiB, QD32)	Up to 43,000 IOPS
Typical Latency (Read / Write)	115 µs / 35 µs

4. Endurance, Reliability & Data Protection

Operational Endurance Class

• Workload Classification: Mixed-Use (MU)

• Drive Writes Per Day (DWPD): 3.0 DWPD (Calculated across a 5-year production deployment lifecycle)

• HPE SmartSSD Wear Gauge: Fully integrated. System administrators can track live wear indicators through HPE iLO or Systems Insight Manager to plan proactive hot-plug lifecycle maintenance.

Hardware-Level Safeguards

• MTBF (Mean Time Between Failures): 2.5 Million Hours

• UBER (Uncorrectable Bit Error Rate): Less than 1 sector error per $10^{17}$ bits read

• Dual-Port High Availability: True active-active dual-port SAS architecture provides redundant signal pathways down to the backplane, avoiding single points of failure (SPOF) in multi-path storage fabrics.

• Power Loss Protection (PLP): Outfitted with robust on-board hardware storage capacitors that safely flush volatile cache registers directly into non-volatile logic gates during sudden rack or host power termination.

• End-to-End Data Path Protection: T10-DIF parity checking prevents silent data corruption or bit degradation across internal data paths.

5. Physical, Electrical & Environmental Parameters

Dimensions & Weights

• Physical Profile: 15.0 mm (Height) x 69.85 mm (Width) x 100.45 mm (Depth)

• Net Weight: ~0.62 lbs (~280 g) including the SmartCarrier frame assembly.

Electrical Load Profiles

• Operating Input Voltage: Dual Rail inputs ($+5\text{VDC} \pm 5\%$ and $+12\text{VDC} \pm 5\%$)

• Active Operational Power (Max): ~9.0 Watts

• Idle State Power Consumption: ~3.9 Watts

Environmental Limits

• Operating Ambient Temperature: 10°C to 35°C (50°F to 95°F)

• Non-Operating Storage Range: -40°C to 70°C (-40°F to 158°F)

• Operating Shock Limit: 1,000 G for 0.5 ms

6. Enterprise System Compatibility

This drive includes genuine HPE digitally signed firmware to verify system authenticity, clear iLO storage errors, and sync seamlessly with HPE Smart Array controllers.

Compatible HPE ProLiant Server Platforms:

• HPE ProLiant Gen8 Platforms: DL160, DL320e, DL360p, DL380p, DL560, ML350p (SFF small form factor chassis)

• HPE ProLiant Gen9 Platforms: DL20, DL60, DL80, DL120, DL160, DL180, DL360, DL380, DL560, DL580, ML30, ML110, ML150, ML350

• HPE ProLiant Gen10 Platforms: DL20, DL160, DL180, DL325, DL360, DL380, DL385, DL560, DL580, ML30, ML110, ML350

• HPE Apollo Systems: 4200, 4500, XL170r, XL190r high-density storage frameworks
