Inspur TS860M5 Mission-Critical Server
Technical Datasheet & Product Overview
The Inspur TS860M5 is an enterprise-grade, 8-socket high-density mission-critical server designed for core business databases, large-scale virtualization, SAP HANA, real-time analytics, and enterprise resource planning (ERP) workloads. Built on the Intel® Xeon® Scalable processor platform, it offers high compute density, flexible scalability, and over 80 hardware/firmware-level Reliability, Availability, and Serviceability (RAS) features.
Key Highlights
-
Extreme Compute Density: Houses up to 8 processors in a high-efficiency 4U chassis, providing up to 224 cores and 448 threads.
-
Massive Memory Capacity: Equipped with 128 DDR4 DIMM slots, supporting up to 16 TB of system memory (or up to 24 TB with Intel® Optane™ Persistent Memory).
-
Hard Partitioning Support: Supports physical hardware partitioning (e.g., splitting into two independent 4-socket systems) for workload isolation and cloud consolidation.
-
Enterprise RAS Architecture: Incorporates advanced fault tolerance, MCA (Machine Check Architecture) recovery, thermal/voltage redundancy, and hot-swappable components.
Technical Specifications
| Specification Category | Detailed Description |
| Form Factor | 4U Rack Server |
| Processors | Up to 8x 1st or 2nd Generation Intel® Xeon® Scalable Processors (Platinum 8100 / 8200 series) |
| Interconnect | Intel® Ultra Path Interconnect (UPI) fully meshed topology |
| Memory Slots | 128x DDR4 DIMM slots (2666 / 2933 MHz) |
| Max Memory Capacity |
• Up to 16 TB DDR4 RDIMM/LRDIMM
• Up to 24 TB combined with Intel® Optane™ Persistent Memory (PMem 100 Series) |
| Drive Bays & Storage |
• Up to 24x 2.5″ SAS/SATA/NVMe SSDs or up to 12x 3.5″ SAS/SATA HDDs
• Dual internal M.2 SSDs for OS boot |
| Storage Controllers | Hardware SAS/SATA/NVMe RAID controllers (RAID 0, 1, 5, 6, 10, 50, 60) with cache protection |
| PCIe Expansion | Up to 30x PCIe 3.0 expansion slots (supports PCIe hot-plug, GPU cards, and HBAs) |
| Network Interfaces | Flexible OCP 2.0 / PHY mezzanine options: 1GbE, 10GbE (RJ45/SFP+), 25GbE (SFP28), and 100GbE / InfiniBand HBAs |
| Power Supplies | Up to 8x hot-swappable Platinum / Titanium level redundant PSUs (supports N+N / N+M redundancy) |
| Cooling | N+1 redundant, hot-swappable system cooling fan modules |
| System Management | Inspur Server Management Controller (ISMC), IPMI 2.0, Redfish API, Web GUI, iKVM, dedicated GbE management port |
| Operating Systems | Red Hat Enterprise Linux (RHEL), SUSE Linux Enterprise Server (SLES), VMware vSphere / ESXi, Microsoft Windows Server |
Hardware RAS & Reliability Features
High Availability Design: The TS860M5 is engineered to deliver 99.999% system availability through fault prevention, hardware isolation, and automated recovery mechanisms.
-
Physical Hardware Partitioning: Configurable as a single 8-socket system or two independent 4-socket physical partitions.
-
Memory RAS: Memory Mirroring, Memory Rank Sparing, Advanced ECC, SDDC (Single Device Data Correction), and ADDDC (Adaptive Double Device Data Correction).
-
Fault Isolation & Hot-Swap: Hot-swappable power supplies, fans, storage drives, and select PCIe expansion modules to eliminate unplanned downtime.
-
Real-time Diagnostics: Integrated ISMC controller monitors system health (voltages, temperatures, fan status) with predictive failure analysis (PFA).
Target Workloads & Applications
-
Mission-Critical Core Databases: Oracle DB, Microsoft SQL Server, IBM DB2, and SAP HANA.
-
Enterprise Resource Planning (ERP): High-concurrency ERP, CRM, and financial core processing systems.
-
Large-Scale Virtualization: High-density VM deployment via VMware vSphere, KVM, or OpenStack.
-
In-Memory Computing: Real-time financial transaction processing, fraud detection, and big data analytics.
