Huawei S1700-52R-2T2P-AC Switch – Full Product Specifications

Name: Huawei S1700-52R-2T2P-AC Switch - SunSpike
SKU: S1700-52R-2T2P-AC

Product Overview

The Huawei S1700-52R-2T2P-AC is a next-generation energy-saving Ethernet access switch designed for small and medium-sized enterprises, Internet cafes, hotels, and schools. It is an unmanaged Layer 2 switch that is easy to install and maintain, offering a wide array of features to help customers build secure, reliable, and high-performance networks.

Key highlights of the S1700 series include:

Fan-free design for silent operation and reduced power consumption
Energy Efficient Ethernet (EEE) support, enabling ports to enter power-saving mode during low traffic periods
Non-blocking Layer 2 wire-speed forwarding on all ports
One-key operation button on the front panel for easy management

The S1700-52R-2T2P-AC is classified as an unmanaged switch within the S1700 series.

Main Specifications

Item	Description
Product Type	Fast Ethernet Switch
Application Layer	Layer 2
Switch Type	Unmanaged
Switching Capacity	17.6 Gbit/s
Packet Forwarding Rate	13.2 Mpps
MAC Address Table	8K entries
Port Structure	Non-modular
Total Ports	52 ports
Dimensions (H × W × D)	43.6 mm × 442.0 mm × 220.0 mm (1.72 in. × 17.40 in. × 8.66 in.)
Weight	2.54 kg (5.60 lb)
Maximum Power Consumption	< 22.6 W (100% throughput)
Part Number	98010456

Port Configuration

Port Type	Quantity	Description
10/100Base-TX Ethernet Ports (Fast Ethernet RJ45)	48	Copper ports supporting 10/100 Mbps
10/100/1000Base-T Ethernet Ports (Gigabit Ethernet RJ45)	2	Copper GE uplink ports
Gigabit SFP Ports (Optical)	2	Fiber GE uplink ports

The switch provides both electrical and optical Gigabit uplink ports, facilitating user access with cost-effective connectivity options.

Technical Specifications

Power Supply

Parameter	Specification
Rated Voltage Range	100 V AC to 240 V AC, 50/60 Hz
Maximum Voltage Range	90 V AC to 264 V AC, 47 Hz to 63 Hz
Power Supply Type	AC only

Environmental Specifications

Parameter	Specification
Operating Temperature	0°C to 45°C (32°F to 113°F) at 0–1800 m altitude
Operating Temperature (High Altitude)	Reduces by 1°C per 220 m increase when altitude is 1800–5000 m
Storage Temperature	-20°C to +70°C (-4°F to +158°F)
Relative Humidity	10% to 90%, noncondensing
Operating Altitude	0–3500 m (0–11483 ft.)
Noise Level	Noise-free (no fans) at 27°C
Cooling Method	Fan-free, natural heat dissipation

LED Indicators

Indicator	Status	Description
Power Indicator	Steady green	The switch is powered on
	Off	The switch is powered off
Ethernet Electrical Port Indicator	Steady green	A port has established a 10M or 100M connection
	Blinking green	A port is transmitting data
	Off	A port is not connected
GE1–GE2 Electrical Port Indicator	Steady green	A port has established a 1000M connection
	Blinking green	A port is connected at 1000 Mbit/s and transmitting data
	Steady yellow	A port has established a 10M or 100M connection
	Blinking yellow	A port is transmitting data at 10/100 Mbit/s
	Off	A port is not connected
GE3–GE4 Optical Port Indicator	Steady green	A port has established a 1000M connection
	Blinking green	A port is connected at 1000 Mbit/s and transmitting data
	Off	A port is not connected
