SSD D5-P5316 Series SSDPFKXK019T1

Product Overview: SSDPFKXK019T1

Product Line: Solidigm™ (formerly Intel®) SSD D5-P5316 Series

Form Factor: U.2 15mm

Capacity: 15.36 TB

Interface: PCIe 4.0 x4, NVMe

NAND Flash Memory: 144-Layer QLC 3D NAND

Technical Specifications

1. Performance

• Sequential Read (128KB): Up to 7,000 MB/s

• Sequential Write (128KB): Up to 3,600 MB/s

• Random Read (4KB): Up to 800,000 IOPS

• Random Write (16KB): Up to 130,000 IOPS

• Read Latency (Typical): 110 µs

• Write Latency (Typical): 15 µs

2. Endurance & Reliability

• Endurance (DWPD): 0.41 DWPD (Random) / Up to 5.0 DWPD (Sequential)

• Lifetime Writes (TBW): Up to 22.9 PBW (4KB Random) / 110.1 PBW (64KB Sequential)

• Mean Time Between Failures (MTBF): 2.0 million hours

• Uncorrectable Bit Error Rate (UBER): $< 1 \text{ sector per } 10^{17} \text{ bits read}$

• Warranty: 5 Years

3. Power Consumption & Thermal

• Active Power Consumption: Up to 25 W

• Idle Power Consumption: $< 5 \text{ W}$

• Operating Temperature: $0^\circ\text{C}$ to $70^\circ\text{C}$

4. Advanced Features & Security

• Data Protection: End-to-End Data Protection, Power Loss Data Protection (PLP)

• Encryption / Security: AES 256-bit Hardware Encryption, TCG Opal 2.0 / Sanitize Flash Erase (varies by SKU variant)

• Monitoring: High-precision Thermal Monitoring, SMART Attribute Tracking
