Name: Oracle Sun Netra X4270 M3 Rack Mount Server - SunSpike
SKU: X4270-M3

Part No.	netrax4270m3
Manufacturer	Sun Oracle
Rack Units	2 U
Height	87
Width	445
Depth	527.8
Weight [Kg]	18.50
Specification	NEBS: NEBS Level 3 certified by Telecordia Seismic: GR-63-CORE requirements for earthquake Zone 4
CPU Socket(s)	2 Intel® Xeon® E5-2600, with QuickPath Interconnect
Compatible CPU(s)	2.1 GHz, 95W, 8 Core
Max CPU Clk Spd	2.1 GHz
CPU Cache	Level 1: 32 KB instruction and 32 KB data L1 cache per core; Level 2: 256 KB shared instruction/data L2 cache per core; Level 3: Up to 20 MB shared inclusive L3 cache per processor
Max # Core(s)	8 per CPU
Memory Slot(s)	16x DDR3 Low Voltage RDIMM (LV RDIMM options: 8 GB at up to 1,600 MHz, 16 GB at up to 1,600 MHz)
Memory Capacity	256 GB
Drive Bays	Eight-disk chassis, eight 2.5″ SAS-2 front-accessible, hot-swappable disk drives with no DVD-RW; or Six-disk chassis, six 2.5″ SAS-2 front-accessible, hot-swappable disk drives and DVD-RW
Capacity	Up to 4.8 TB
HDD Suitability	300 GB, or 600 GB 10krpm
RAID Options	Optional RAID levels: 0, 1, 1E, 5, 5EE, 6, 10 with optional Battery Backup Write Cache (BBWC) via optional SAS HBA PCIe Card.
Supported OS	Oracle Linux Oracle Solaris (pre-installed option) Red Hat Enterprise Linux SUSE Linux Enterprise Server Microsoft Windows Server
USB Port(s)	Six 2.0 USB ports (two front, two rear, two internal)
PCI Slot(s)	Six PCIe 3.0 LP slots – six (6) x8-lane slots
LAN Socket(s)	Four 10/100/1000/10G Base-T Ethernet ports
Bandwidth	10 GbE
Graphics / GPU	VGA 2D graphics controller embedded
Resolution (Native)	Supports resolutions up to 1,280 x 1,024 x 16 bits @60 Hz (1,024 x 768 when viewed remotely via Oracle ILOM RKVMS)
Standard	The Sun Netra X4270 M3 server comes with a one-year warranty.

The Sun Netra X4270 M3 server helps cut costs and lower risks with comprehensive virtualization, a choice of world-class Oracle operating systems, and a complete cloud optimized infrastructure, all built in, at no extra charge. Proven effective across a wide range of applications and under the most demanding conditions, Oracle’s Sun Netra X4270 M3 server allows telecommunication customers to shorten time to develop and deploy new services.
