Lenovo ThinkServer RD640 Servers

Lenovo RD640 Information
The Lenovo ThinkServer RD640 server is a dual-socket 2U workhorse server that’s ideal for database, analytics, and other common business applications. Lenovo’s Smart Grid management technology and support for low-voltage memory modules help keep energy expenses low. Powered by either one or two Intel’s Xeon E5-2600 processors, the Lenovo ThinkServer RD640 server provides up to 32TB of storage in just a 2U chassis. In a dual-processor configuration, the system will support up to 20 DIMM slots. One or two Intel Xeon E5-2600 or E5-2600 v2 CPUs are used in this dual-socket server. The E5-2600 v2 CPUs have 50 percent more cache and cores than prior generation processors, resulting in a 35 percent gain in performance.

Lenovo RD640 Specifications
Chipset: Intel C602J

Memory: 20 DIMM sockets. 12 sockets for CPU 1, 8 sockets for CPU 2

Memory type: 1600MHz, LV RDIMM, DDR3, 4-channel per processor, 240-pin

Disk Bays: 8 x 3.5-inch hot-swap SATA/SAS, 16 x 2.5-inch hot-swap SATA/SAS

Network Interface: 2 Gb Ethernet ports, 1 Gb Ethernet port (dedicate/share management)

Power Supply: Up to 2 x 800-watt standard, 80 PLUS® Gold qualified
