Lenovo 900GB 2.5″ 10K 12G SAS HDD 00YK015

Lenovo 900GB 10K 12Gbps SAS 2.5″ SFF Enterprise Hot-Swap Hard Drive

SKU: 00YK015 Category: Brand: ,
Request a quote Email SKU

Enterprise stock · tested · export documentation available

Lenovo 900GB 10K 12Gbps SAS 2.5″ SFF Enterprise Hot-Swap Hard Drive

Overview

The Lenovo 00YK015 (associated with Retail/Option Part Number 7XB7A00026) is an enterprise-class, high-density 900 Gigabyte (GB) internal hard disk drive. Engineered specifically for late-generation Lenovo ThinkSystem servers, it combines a fast 10,000 RPM rotational spindle speed with a high-bandwidth 12 Gbps Serial Attached SCSI (SAS-3) interface.

This drive provides the ultra-low transactional latency and robust IOPS throughput required for multi-tenant virtualization, enterprise databases, and mission-critical cloud storage tiers. It comes mounted on Lenovo’s toolless, hot-swappable ThinkSystem G4HS (Generation 4 Hot-Swap) SFF drive carrier tray.

Technical Specifications

Parameter Specification Details
Brand / Vendor Lenovo
Retail Option Part Number (OPN) 7XB7A00026
FRU Part Number (FRU P/N) 00YK015
Component Model Reference ST900MM0009 (Seagate OEM) / AL14SX (Toshiba OEM) series equivalents
Formatted Storage Capacity 900 GB
Interface Standard Dual-Port SAS 12.0 Gbps (SAS-3 architecture compliant)
Spindle Rotational Speed 10,000 RPM
Data Format / Sector Type Native 512-byte sectors (512n block structure)
Recording Technology Conventional Magnetic Recording (CMR)
Form Factor 2.5-inch Small Form Factor (SFF) × 15mm standard z-height

Performance & Reliability Metrics

  • Sustained Interface Transfer Rate: Up to 210 MB/s to 215 MB/s sequential read/write execution.

  • Dual-Port High Availability: Equipped with standard dual-port physical routing paths to support active failover, multipath I/O (MPIO), and link aggregation within modern high-availability SAN arrays and RAID nodes.

  • Mean Time Between Failures (MTBF): Rated at 2.0 million hours for high-stress, 24/7 continuous data center operational profiles.

  • Hot-Swap Carrier Integration: Pre-assembled onto the standard ThinkSystem SFF Caddy, featuring a heavy-duty locking lever and integrated optical light pipes for system backplane LED activity and status signaling.

Server Platform Compatibility

The 00YK015 / 7XB7A00026 drive assembly is engineered explicitly for Lenovo ThinkSystem (Intel Xeon Scalable / AMD EPYC based) server lines and is not backwards-compatible with legacy IBM System x (Gen3/G3HS) backplanes.

Target Supported Lenovo ThinkSystem Infrastructure

  • ThinkSystem Rack Servers: SR530, SR550, SR570, SR590, SR630, SR650, SR850, SR860, SR950

  • ThinkSystem Tower Servers: ST550, ST558

  • ThinkSystem Blade & Dense Compute Nodes: SN550, SN850, SD530

  • ThinkSystem Storage Arrays: DE2000H, DE4000H, DE6000H series setups configured for 2.5-inch SFF expansion drives.
