Inspur NF5270M4 2U Rack Server

20 DDR4 DIMM slots (Supports ECC RDIMM / LRDIMM)

Up to 1.25TB max memory capacity

Front Drive Options:

• Option 1: Up to 16x or 24x 2.5″ hot-plug SATA/SAS HDDs or SSDs

• Option 2: Up to 8x or 12x 3.5″ hot-plug SATA/SAS HDDs or SSDs

(3.5″ trays feature dual mounting holes for 2.5″ SSD integration)

Rear Drive Option:

• Up to 2x 2.5″ hot-plug rear SATA/SAS HDDs or SSDs

• Onboard SATA controller via Intel PCH

• Optional 6Gb/s or 12Gb/s SAS HBA / RAID controllers (RAID 0/1/5/6/10/50/60 with optional cache & supercap protection)

Up to 6 PCIe 3.0 slots (3x PCIe x16 + 3x PCIe x8):

• 5x PCIe 3.0 expansion slots via riser cards

• 1x PCIe 3.0 x8 Mezzanine slot for dual-port 10G SFP+ or 10G-BaseT card

• Onboard dual-port 1GbE (Intel i350 controller)

• 1x Mezzanine slot supporting 10G SFP+ or 10G-BaseT upgrade

Front: 1x USB port, 1x VGA port

Rear: 2x USB 3.0 ports, 1x VGA port, 1x dedicated RJ-45 management port, 1x Serial port

Internal: Internal USB ports & serial interface

Onboard Aspeed BMC chipset

Supports IPMI 2.0, KVM over IP, Virtual Media, and Intel Node Manager 3.0

Platinum or Titanium level high-efficiency power supplies (PMBus compliant)

550W / 800W modules with optional 1+1 hot-swap redundancy

Height: 87 mm (3.43 in) | Width: 447 mm (17.6 in) | Depth: 720 mm (28.35 in)

Weight: approx. 35 kg (78 lbs) max configuration

Microsoft Windows Server 2012 / 2012 R2 / 2016

Red Hat Enterprise Linux 6 / 7

SUSE Linux Enterprise Server 11 / 12

VMware ESXi / Ubuntu Server / CentOS
