Name: Inspur/IEIT NF5280G7 2U Rack Server - SunSpike
SKU: NF5280G7

The Inspur / IEIT NF5280G7 is a high-end 2U dual-socket rack server powered by AMD EPYC™ 9004 series processors. Designed for compute-intensive workloads, high-density virtualization, AI inference, and big data analytics, it delivers massive core density, ultra-high memory bandwidth via 12 DDR5 channels per socket, PCIe 5.0 expansion, and flexible enterprise storage configurations.

Technical Specifications Overview

Category	Specifications
Form Factor	2U Rack Server
Processors	Up to two AMD EPYC™ 9004 Series Processors • Up to 128 cores and 256 threads per CPU • Up to 400W TDP per CPU • Up to 1,150 MB L3 Cache per CPU • 4 × 32GT/s xGMI / Infinity Fabric links per CPU
Memory	• 24 × DDR5 DIMM slots (12 channels per CPU) • Memory speeds up to 4800 MT/s • Supports RDIMM and 3DS RDIMM with ECC • Maximum memory capacity up to 6 TB
Drive Bays & Storage	Front Options: • Up to 12 × 3.5-inch SAS/SATA/NVMe drives • Up to 24 × 2.5-inch SAS/SATA/NVMe/E3.S drives • Up to 25 × 2.5-inch SAS/SATA drives (supports up to 4 × NVMe) Rear Options: • Up to 4 × 3.5-inch SAS/SATA drives • Up to 4 × 2.5-inch SAS/SATA/NVMe drives • Up to 2 × M.2 SSDs or 2 × E1.S SSDs Internal Options: • Up to 2 × SATA M.2 or 2 × PCIe x4 NVMe M.2 SSDs • Up to 4 × 3.5-inch SAS/SATA drives
Storage Controllers	• PCIe 4.0/5.0 SAS HBAs and hardware RAID controllers (12Gbps SAS support) • Onboard NVMe controllers / Software RAID support
Expansion Slots	• Up to 8 × standard PCIe 5.0 expansion slots (Air-cooled: up to 8; Liquid-cooled: up to 7) • Supports up to 4 × double-width GPUs or 8 × single-width GPUs • 2 × hot-swappable OCP 3.0 x16 slots (supports Multi-host)
Network Interfaces	• 2 × OCP 3.0 network mezzanine cards • Interface choices: 1GbE, 10GbE, 25GbE, 40GbE, 100GbE, and 200GbE
I/O Ports	Front: 1 × USB 3.0, 1 × USB 2.0, 1 × DB15 VGA Rear: 2 × USB 3.0, 1 × DB15 VGA, 1 × Micro-USB serial port, 1 × Dedicated RJ45 IPMI management port
Power Supply	• Hot-swappable CRPS standard PSUs in 1+1 redundant configuration • Options: 550W, 800W, 1300W, 1600W, 2000W, or 2700W (80 PLUS Platinum / Titanium certified)
Cooling System	• 6 × hot-swappable N+1 redundant dual-rotor fans • Supports intelligent zonal cooling regulation & optional cold-plate liquid cooling solutions
System Management	• Integrated Baseboard Management Controller (BMC) • Dedicated 1GbE IPMI remote management port • Supports IPMI 2.0, Redfish, Web UI, virtual KVM, virtual media, and cloud automated O&M
Security Features	• TPM 2.0 (Trusted Platform Module) & TCM (Trusted Cryptography Module) • Two-factor authentication, chassis intrusion alarm, BMC/BIOS redundancy
Dimensions (W × H × D)	• With mounting ears: 482.4 mm × 87 mm × 828.4 mm • Without mounting ears: 435 mm × 87 mm × 800 mm
Weight	Full configuration: ≤ 30 kg to 33 kg
Supported OS	Microsoft Windows Server, Red Hat Enterprise Linux (RHEL), SUSE Linux Enterprise Server (SLES), VMware ESXi, Ubuntu, CentOS
