HUAWEI S5600 5800 6800 V3 V5 Power AC Power Module 02310UWW HSP1800-S12A 1800W
HUAWEI PN: 02310UWW HSP1800-S12A 1800W
Product Identification
- Product Type: High-Power AC Power Module
- Part Number (P/N):
02310UWW - Model:
HSP1800-S12A - Rated Power: 1800W
Key Specifications
| Feature | Details |
|---|---|
| Input Voltage | AC 100-240V (Wide Range) |
| Output Power | 1800W Max |
| Form Factor | Standard Server/Switch Power Module |
| Compatibility | Huawei S5800 / S6800 V3 / V5 Series Switches |
Application Context
This power module is designed for Huawei CloudEngine S5800 and S6800 V3/V5 series switches. It is typically used in:
- High-Density Configurations: For switches with 48x10G/25G ports or PoE+ models requiring higher power budgets.
- Redundancy: Usually deployed in 1+1 or N+1 redundant configurations to ensure zero downtime.
- Hot-Swappable: Supports hot-plug installation/removal without shutting down the chassis.
Important Notes
- Not for S5600: The S5600 series uses older, lower-wattage power modules (e.g., PSL130-AD/PSL180-AD). Do not attempt to install this 1800W module in an S5600 chassis; the form factor and backplane connectors are incompatible.
- Airflow: Ensure the module’s airflow direction (Front-to-Back or Back-to-Front) matches your chassis and other installed modules to prevent thermal shutdown.
- Firmware: Ensure your switch runs a V3/V5 compatible release (e.g., V200R005 or later) to recognize the
HSP1800-S12Avia SNMP/CLI.
