HPE ProLiant DL380a Gen11 Server
DL380a Gen11
Enterprise stock · tested · export documentation available
HPE ProLiant DL380a Gen11 Server Overview
The HPE ProLiant DL380a Gen11 is a 2U, 2-socket rack-mountable server specially optimized for high-density GPU accelerators, artificial intelligence (AI), machine learning (ML), virtual desktop infrastructure (VDI), and compute-intensive enterprise workloads. Powered by 4th and 5th Generation Intel® Xeon® Scalable Processors, it combines high memory capacity, PCIe Gen5 bandwidth, and advanced thermal design to support top-tier graphics processing units (GPUs).
Technical Specifications
| Feature Category | Specification / Capability |
| Form Factor | 2U Rack Mount |
| Processor Type | 4th or 5th Generation Intel® Xeon® Scalable Processors |
| Processor Sockets | 2 Sockets (Supports up to 350W TDP per processor) |
| Processor Cores | Up to 64 cores per processor (up to 128 cores total) |
| Memory Type | HPE DDR5 SmartMemory |
| Memory Slots | 32 DIMM slots (16 DIMMs per processor, 8 channels per CPU) |
| Maximum Memory | Up to 8 TB (using 256 GB DDR5 Registered DIMMs) |
| Accelerator Support |
• Up to 4 Double-Wide (DW) GPUs (e.g., NVIDIA H100, L40S, A100) • Up to 8 Single-Wide (SW) GPUs (e.g., NVIDIA L4) |
| PCIe Expansion | Up to 4 PCIe 5.0 x16 slots via riser assemblies |
| Storage Bays |
• Up to 8 SFF (2.5″) NVMe / SAS / SATA SSDs • Optional support for E3.S EDSFF NVMe drives |
| Storage Controller | HPE Smart Array / Tri-Mode Controllers (SR / MR Series) or onboard SATA |
| Network Controller | OCP 3.0 Small Form Factor slot (10GbE, 25GbE, 100GbE, or 200GbE adapters) |
| Management Engine | HPE iLO 6 (Integrated Lights-Out 6), HPE OneView, HPE GreenLake |
| Power Supply | Hot-plug redundant HPE Flex Slot Power Supplies (1600W, 1800W-2200W Titanium/Platinum) |
| System Cooling | High-Performance hot-plug redundant fans |
| Security Features | HPE Silicon Root of Trust, TPM 2.0, Secure Boot, Chassis Intrusion Detection |
Key Features & Highlights
-
GPU-Optimized Architecture: Designed with specialized front and rear airflow pathways to keep high-TDP GPUs and processors operating efficiently under sustained heavy loads.
-
PCIe Gen5 Bandwidth: Delivers double the data transfer rates compared to Gen4, providing ultra-low latency data exchange between CPUs, system memory, and installed GPUs.
-
DDR5 High-Speed Memory: Operates at up to 4800 MT/s or 5600 MT/s (depending on processor generation), optimizing throughput for memory-bound applications.
-
Enterprise Security: Built with HPE’s Silicon Root of Trust, establishing a hardware-anchored chain of trust that verifies firmware prior to boot.
-
Remote Management: Integrated HPE iLO 6 enables full out-of-band monitoring, health reporting, thermal management, and automated troubleshooting.
Target Workloads
-
Artificial Intelligence & Deep Learning: Neural network training, LLM fine-tuning, and real-time AI inference.
-
Virtual Desktop Infrastructure (VDI): Multi-user graphics acceleration and CAD/3D rendering environments.
-
High-Performance Computing (HPC): Scientific simulation, financial modeling, and complex analytics.
-
Data Analytics & Acceleration: In-memory databases and accelerated data processing pipelines.
